Spotting drills, centre drills Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
150320 NC spotting drill 120°

HSS-E Futura

P M K N
Cu, AI

Type N, HSS-E, Futura, cylindrical shank.
Tolerance d1: h6
Order ID d1 l2 l1 Order ID d1 l2 l1
mm mm mm mm mm mm
150320.0100 3 10 50 150320.0700 12 30 102
150320.0200 4 12 52 150320.0800 14 35 115
150320.0300 5 15 60 150320.0900 16 35 115
150320.0400 6 20 66 150320.1000 18 40 130
150320.0500 8 25 79 150320.1100 20 40 131
150320.0600 10 25 89 150320.1200 25 45 138
150220 Assortment of NC spotting drills
HSS-E

P M N
Cu, AI

Packed with NC spotting drills made from HSS-E, 150000, in sturdy plastic case.
Order ID Angle No. of NC spotting drills Range
mm
150220.0100 90° 6 4 / 5 / 6 / 8 / 10 / 12
150220.0200 120° 6 4 / 5 / 6 / 8 / 10 / 12
150130 Solid carbide NC spotting drill 90° FUTURO
VHM

P M K N
Cu, AI

Without flat. Extra stable design.
Order ID d1 l2 l1 Order ID d1 l2 l1
mm mm mm mm mm mm
150130.0100 3 9 38 150130.0400 8 27 63
150130.0200 4 10 50 150130.0500 10 30 72
150130.0300 6 13 57 150130.0600 12 35 83
150140 Solid carbide NC spotting drill 90° FUTURO

VHM TiAIN

P M K N S
Cu, AI Ti

Without flat, TiAlN. Extra stable design.
Order ID d1 l2 l1 d2 Order ID d1 l2 l1 d2
mm mm mm mm mm mm mm mm
150140.0100 3 9 38 3 150140.0400 8 27 63 8
150140.0200 4 10 50 4 150140.0500 10 30 72 10
150140.0300 6 13 57 6 150140.0600 12 35 83 12
