Levelling and gradient measuring instru- Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
075220 Built-in spirit level WYLER
Type 66, sensitivity 0.1 mm/m
Swiss made - For screwing onto machines, equipment etc.
Note:
Delivered with other degrees of sensitivity on request:
1.0 mm/m in lengths from 50...150 mm
2.0...5.0 mm/m in lengths from 30...150 mm
Order ID Length Width Height Hole spacing for thread
mm mm mm mm
0.3 mm/m 075220.0100 100 18 22 86 M 4
075220.0200 120 18 22 105 M 4
075220.0300 150 18 22 135 M 4
075240 Built-in spirit level WYLER
Type 66, sensitivity 0.3 mm/m
Swiss made - For screwing onto machines, equipment etc.
Note:
Delivered with other degrees of sensitivity on request:
1.0 mm/m in lengths from 50...150 mm
2.0...5.0 mm/m in lengths from 30...150 mm
Order ID Length Width Height Hole spacing for thread
mm mm mm mm
0.3 mm/m 075240.0100 60 12 14 50 M 3
075240.0200 80 15 18 70 M 4
075240.0300 100 18 22 86 M 4
075240.0400 120 18 22 105 M 4
075240.0500 150 18 22 135 M 4
075260 Horizontal spirit level WYLER
Type 69B, sensitivity 0.3 mm/m
Swiss made - With V-notch base.
Order ID Length Width Height Order ID Length Width Height
mm mm mm mm mm mm
075260.0100 100 30 35 075260.0300 200 30 35
075260.0200 150 30 35 075260.0400 300 30 35

075280 Tubular spirit level WYLER
Type 59, sensitivity 0.1 mm/m
Swiss made - With flat base.
Note:
Available with 1.0 mm/m sensitivity on request
Order ID Length Width Ø Order ID Length Width Ø
mm mm mm mm mm mm
075280.0100 80 9 16 075280.0300 150 10 22
075280.0200 100 10 20 075280.0400 200 11 22
0.1 mm/m
075285 Pipe-level FUTURO
Sensitivity 0.7 mm/m
With low base, among other things suitable for civil engineers, etc.
Features:
Touch down spirit level
Aluminium profile gold anodised
Precision-glass level
Spirit level stored shock-proof
Light cover
Note:
Floor area not adjusted - use adjusting spring!
Order ID Length Width Ø
mm mm mm
075285.0100 150 20 35
075300 Shaft spirit level WYLER
Type A 63, sensitivity 0.05 mm/m
Swiss made - With side slots and V-notch base.
Note:
Also available with sensitivity 0.1 mm/m and 1.0 mm/m on request
Package contents:
Delivered in holster.
0.3 mm/m Order ID Length Width Height Order ID Length Width Height
mm mm mm mm mm mm
075300.0100 100 30 35 075300.0300 200 30 35
075300.0200 150 30 35

398 Brütsch/Rüegger Tools Ltd. • Heinrich Stutz-Strasse 20 • P.O. Box • CH-8902 Urdorf • www.brw.ch
