Levelling and gradient measuring instru- Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
075750 Inclinometer digital PRO
Digital gauge with display of up to 360°. Immediate reading of evenness, rectangularity and all
intermediate angles.
Features:
Electronic sensor
Shock-proof aluminium housing 075750.0100
Base plate with V-groove
Note:
The display rotates 180° for overhead work.
Package contents:
Delivered in transport packaging.
Appropriate batteries:
1 pieces 055050.0700 - 6LR61 / 9.0 V (included in scope of delivery).
Order ID 075750.0100 075750.0200
Range 360° (4 x 90°) 360° (4 x 90°)
Resolution 0.1° 0.01°
Accuracy ± 0.1 °...0.2 ° ± 0.05 °...0.2 °
Dimensions mm 153 x 31 x 51 153 x 31 x 51
Weight kg 0.62 0.62
075800 Clinometer WYLER
CLINOTRONIC PLUS
In hard anodised aluminium housing with 4 precise machined measuring bases. Sensor cell for
improved performance in difficult environmental conditions. Meets the strict EEC standards (imper-
viousness to electromagnetic forces).
Features:
Simple zero point calibration
Measurement displayed in degrees / minutes / seconds / decimal degrees and mm/m
Data output RS-485 / USB
Features software:
The CLINOTRONIC PLUS unit is supplied with an USB connecting cable and the „LabEXCEL Clino“
evaluation software. The software enables to display the measured values. The measurement re-
sults can be transferred to an EXCEL file for further processing.
Package contents:
Delivered in transport packaging incl. Software „LabEXCEL Clino“ and signal cable USB 1.8 m.
Appropriate batteries:
1 pieces 055050.0300 - LR6 / 1.5 V (AA) (included in scope of delivery).
Order ID 075800.0100
Range ±45°
Resolution mm/m 0.02
Accuracy < 2‘
Size mm 100 x 30 x 75
Weight kg 0.5

076015 Cross-line laser
SuperCross-Laser Compact
Automatic cross-line laser in pocket format with 2 easily visible laser lines to support alignment
work.
Features:
Automatic level/ Automatic alignment due to magnetically damped pendulum system
Out-of-level / Optical warning if device is outside the level range
Transport lock / Transport protection by locking pendulum
Inclination mode for aligning slants
Legs folding in and out
Range of laser >10m (depending on lighting conditions)
Accuracy 5 mm/10 m
Self-levelling range 4°
Dimensions (W x H x D) 35 x 153 x 36 mm
Accuracy 5 mm/10m
Package content:
Supplied in transport packaging including bag and user instructions.
Appropriate batteries:
1 pieces 055050.0300 - LR6 / 1.5 V (AA) (included in scope of delivery).
Appropriate accessories:
Elevator stand 074912.0200
Order ID 076015.0100

074912 Accessories SCL
Order ID Designation
074912.0200 Aluminium elevator stand with combination tips (rubber/steel) and 5/8“ thread
adapter
