Levelling and gradient measuring instru- Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
075520 Frame spirit level WYLER
Type 58S, sensitivity 0.3 mm/m
Swiss made - For measuring horizontal and vertical surfaces and shafts.
Features:
2 flat and 2 V-notch bases
Ground
Lengthwise and crosswise bubble indicators
Bubble indicator guard
Insulated handles all-round
Note:
Other sizes on request
Package contents:
0.04 mm/m
Delivered in holster.
Order ID Length Width Order ID Length Width
mm mm mm mm
075520.0100 100 x 100 32 075520.0300 200 x 200 40
075520.0200 150 x 150 35 075520.0400 250 x 250 45
075541 Precision frame level FUTURO
Sensitivity 0.02 - 0.10 mm/m
Precision frame level according to DIN 877 for levelling horizontal and vertical surfaces, shafts, etc.,
and for exact alignment of 90° angles.
Designs:
Type P: 3 prismatic bases
Features:
Frames made of high-quality special cast-iron
Frame width 40 mm
One longitudinal and transverse level each made of acrylic glass
Insulated handles on the housing
Glass guard over the levels
Note:
Using an adjusting screw, the longitudinal level can be readjusted to the 0 position without disas-
sembly hassle- and backlash-free.
Package contents:
Delivered in wooden case with factory certificate.
Order ID Type Length Sensitivity Order ID Type Length Sensitivity
mm mm/m mm mm/m
075541.0200 P 150 0.02 075541.1000 P 150 0.10
075541.0210 P 200 0.02 075541.1010 P 200 0.10
075541.0220 P 250 0.02 075541.1020 P 250 0.10
075570 Magnetic spirit level WYLER
Type 48S
Swiss made - For horizontal and vertical measurements, with full magnetic adhesion to vertical
surfaces and shafts. With insulating grip.
Package contents:
Delivered in holster.
Other sensitivities and magnets in both bases upon request
Order ID Measuring surfaces Sensitivity Order ID Measuring surfaces Sensitivity
mm mm/m mm mm/m
075570.0100 150 x 40 0.02 075570.0200 150 x 40 0.05
075610 Angled magnetic spirit level WYLER
Type 47, sensitivity 0.3 mm/m
Swiss made - For vertical measurements, with magnetic adhesion to surfaces and shafts, with
plastic bubble indicator guard. Prism suitable for shaft Ø 17... Ø 80 mm.
Package contents:
Delivered in holster.
Order ID Measuring surfaces Height
mm mm
075610.0100 100 x 30 100

075620 Angled frame spirit level WYLER
Type 79, sensitivity 0.3 mm/m
Swiss made - With two V-notch and two flat bases. With fine adjustment, graduation 2 x
180°, precise 3‘ vernier. Prism suitable for shaft Ø 19... Ø 108 mm.
Package contents:
Delivered in holster.
Order ID Length Width
mm mm
075620.0100 150 x 150 40
0.3 mm/m
