074700 Angle level BMI Winkelstar 715
Robust, fold-up angle gauge made of anodised aluminium, with vertical and horizontal bubble
indicators, for setting or reading angles from 0° to 270°. By turning the ratchet disk, angles can
be locked in steps of 15°.
Order ID Side length Order ID Side length
mm mm
074700.0100 600 / 800 074700.0300 1000 / 1500
074700.0200 600 / 1200 074700.0400 1000 / 2000

074740 Angle measurer digital
Winkeltronic
Measure angles quickly and reliably in awkward places, using the clear digital display. The integra-
ted spirit level helps set the vertical reference.
Features:
LCD display
HOLD function
Zero set of display
Integrated horizontal and vertical bubble
Automatic switchoff

Appropriate batteries:
074740.0050: 2 pieces 055050.0300 - LR6 / 1.5 V (AA) (included in scope of delivery).
074740.0100: 4 pieces 055050.0300 - LR6 / 1.5 V (AA) (included in scope of delivery).
Order ID Range Resolution Accuracy Side length
mm 074740.0050
074740.0050 0...200° 0.1° ±0.2° 400
074740.0100 0...355° 0.1° ±0.1° 600

074743 Angle measurer digital
with integrated clinometer
Angle measuring instrument, clinometer and digital laser level in a single device.
Features:
Digital display for angle and inclination
The display rotates for overhead work
Angle measurement in degrees
Inclination measurement in degrees or percentage
Signal tone in horizontal/vertical position
Saving of the measured value (HOLD)
Laser spot can be switched on
Angles:
Measuring range 0°...180°
Resolution 0.1°
Accuracy ±0.3°
Inclination:
Measuring range 4 x 90°
Resolution 0.1°
Accuracy 0.2°

Appropriate batteries:
3 pieces 055050.0300 - LR6 / 1.5 V (AA) (included in scope of delivery).
Order ID Side length Range laser Size Weight
mm m mm kg
074743.0100 500 20 63 x 30 x 530 1.3
074748 Digital clinometer
with laser-pointer
Electronic clinometer with 180° rotating display for comfortable readout in many positions.
Features:
Inclination display in degrees or percent
Display lighting
Signal tones when approaching 0°/90°
Individual 0° position definable
Magnetic housing
Built-in Laser beam
HOLD function
1/4“ thread for tripod mounting
Appropriate batteries:
3 pieces 055050.0300 - LR6 / 1.5 V (AA) (included in scope of delivery).
Order ID Range Resolution Accuracy Range laser Size Weight
m mm kg
074748.0100 4 x 90° 0.1° ±0.1° 20 32 x 60 x 305 0.67
