Levelling and gradient measuring instru- Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
074600 Magnetic spirit level Antichoc MRM
In light metal alloy, with unbreakable bubbles.
Features:
Accuracy 0.3 mm/m
Accuracy 0.75 mm/m (Inverted measuring)
Model with magnetic clamp
Base with V-groove
Order ID Length Version
mm
074600.1000 300 1 bubble horizontal, 1 bubble vertical
074600.1100 400 1 bubble horizontal, 1 bubble vertical
074600.1200 500 1 bubble horizontal, 1 bubble vertical
074600.1300 600 1 bubble horizontal, 1 bubble vertical
074600.1400 800 1 bubble horizontal, 1 bubble vertical
074600.1510 1000 1 bubble horizontal, 2 bubbles vertical
074640 Metalwork spirit level STANLEY
Aluminium die cast profile, milled measuring surface, with a side magnet and V groove for strong
hold on round steels, 6-point horizontal level for 1% and 2% incline, a vertical level, a level that
can be rotated 360°.
Features:
Accuracy 0.5 mm/m
Order ID Length
mm
074640.0100 250
074650 Spirit level BMI Incli Tronic plus
with integrated clinometer
Angle indicator with read-out in degrees and percentage with large LED display, audible sig-
nal at 0 position. Robust, thick metal section with 2 milled measurement surfaces, and additional
horizontal and vertical bubble indicator.
Features:
Accuracy of the bubble 0.5 mm/m
Accuracy of the digital display:
0° + 90° ±0.05° / 1°...89° ±0.1°
Appropriate batteries:
1 pieces 055050.0700 - 6LR61 / 9.0 V (included in scope of delivery).
Order ID Length Order ID Length
mm mm
074650.0100 600 074650.0200 800
074655 Level
with integrated clinometer
For everyday use at the construction site.
Features:
Accuracy of the bubble 0.5 mm/m
Accuracy of digital display:
0° + 90° ±0.1° / 1°... 89° ±0.2°
180° rotatable LCD display with directional arrows
Operating range 4 x 90°
Acoustic signals on approaching 0° and 90°
Horizontal/vertical level
Recessed grip and hooks on the ends
Readable in °, %, mm, m, inch, ft
Appropriate batteries:
3 pieces 055050.0700 - 6LR61 / 9.0 V (included in scope of delivery).
Order ID Length Order ID Length
mm mm
074655.0100 600 074655.0400 1200
074670 Digital clinometer
Handy and short clinometer that belongs in every tool bag! The flat aluminium legs open on both
sides, so that the clinometer can always be applied properly. The flat design also facilitates making
a marking line.
Features:
Easy calibration
Zero-setting in any position
HOLD function
Appropriate batteries:
1 pieces 055050.1400 - CR2032 / 3.0 V (included in scope of delivery).
Order ID Range Resolution Accuracy Size Weight
mm kg
074670.0100 -45°...+180° 0.05° ± 0.1 ° 250 x 25 x 50 0.34

394 Brütsch/Rüegger Tools Ltd. • Heinrich Stutz-Strasse 20 • P.O. Box • CH-8902 Urdorf • www.brw.ch
