Levelling and gradient measuring instru- Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
074505 Plexiglass spirit level FUTURO
Small, unbreakable acrylic level, cut from a crystal-clear block. Precise, CNC-milled horizontal and
vertical spirit levels.
Features:
Accuracy 1.0 mm/m
Order ID 074505.0100
Size mm 95 x 49 x 15

074515 Multifunction spirit level FUTURO
with marking aid
Measure, mark and align: ALL IN ONE!
Instrument made from light metal alloy, silver-anodised, handy and light.
Standard scale for electricians (71 mm standard scale to DIN 49075 Standard and 30 cm standard
spacing for rapid installation of socket outlets and light switches).
Features:
Accuracy 0.5 mm/m
Accuracy 0.75 mm/m (Inverted measuring)
Unbreakable levels, 1 horizontal and 1 vertical
4 adjustable sliders as marking aids
Order ID Length Profile size
mm mm
074515.0100 800 56 x 18

074520 Plastic spirit level BMI
Robust spirit level of glass fibre-reinforced ABS plastic. Very easy to see round bubble tubes.
Features:
Accuracy 1.0 mm/m
Order ID Length Version
mm
074520.0800 250 Measuring surface with V groove
074520.5800 250 Measuring surface with 2 magnets
074525 T-form spirit level FUTURO
T-form spirit level made of red plastic. Ultra-handy pocket size.
Features:
Accuracy 1.0 mm/m
2 unbreakable acrylic spirit levels
Hole spacing 25 mm / Ø 4.2 mm
Order ID 074525.0100
Size mm 60 x 45 x 13.4

074535 Small spirit level SOLA
Lightweight model of red plastic. Resistant to water, heat and cold.
Features:
Accuracy 1.0 mm/m
1 bubble vertical
1 bubble horizontal
1 bubble for mesures 45°
Order ID Length Version
mm
074535.1000 200 Measuring surface with V groove
074535.1100 200 Measuring surfaces with magnet
074537 Spirit level SOLA
Big X
Very high measuring reliability even in extreme temperatures. Even more precise - thanks to
higher contrast.
Darkening of the areas to the left and right of the bubble edge make the contrast between the
bubble and the vial fluid more than four times better.
Features:
Accuracy 0.5 mm/m
Accuracy 0.75 mm/m (Inverted measuring)
Level with magnifying effect
X profile made of aluminium
Shock-absorbing end caps
Order ID Length Version Order ID Length Version
mm mm
074537.0100 300 1 bubble horizontal 074537.0600 1000 1 bubble horizontal
1 bubble vertical 2 bubbles vertical
074537.0200 400 1 bubble horizontal 074537.0700 1200 1 bubble horizontal
1 bubble vertical 2 bubbles vertical
074537.0300 500 1 bubble horizontal 074537.0800 1500 1 bubble horizontal
1 bubble vertical 2 bubbles vertical
074537.0400 600 1 bubble horizontal 074537.0900 1800 1 bubble horizontal
1 bubble vertical 2 bubbles vertical
074537.0500 800 1 bubble horizontal 074537.1000 2000 1 bubble horizontal
1 bubble vertical 2 bubbles vertical
392 Brütsch/Rüegger Tools Ltd. • Heinrich Stutz-Strasse 20 • P.O. Box • CH-8902 Urdorf • www.brw.ch
