Load and pressure measuring instruments / Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch

073340.0015/.0028 073340.0045/.0050 073340.0065/.0095
Order ID Scales capacity Resolution Platform size Digit height Dimensions WxDxH Weight
kg g mm mm mm kg
073340.0015 0.1 0.001 Ø 81 15 163 x 245 x 79 1.1
073340.0028 0.35 0.001 Ø 81 15 163 x 245 x 79 1.1
073340.0045 1 0.01 130 x 130 15 163 x 245 x 79 1.4
073340.0050 3.5 0.01 130 x 130 15 163 x 245 x 79 1.4
073340.0065 6 0.1 150 x 170 15 163 x 245 x 79 2.0
073340.0095 10 0.1 150 x 170 15 163 x 245 x 79 2.0
073425 Platform scales digital PESOLA
Rugged, compact platform scales with comfortable and simple operation via only 4 buttons. Can
be used as a package scale, industrial scale and counting scale.
Features:
Backlit LCD display with energy save function
Calibration function
Counting function
Display overload and display battery low voltage
Appropriate batteries:
4 pieces 055050.0300 - LR6 / 1.5 V (AA) (included in scope of delivery).
Order ID Scales capacity Resolution Platform size
kg g mm
073425.0300 3 0.1 140 x 140
073430 Weighing platform digital KERN
Robust models for use as industrial scales/counting scales. The display unit is separate from the
platform (cable length 1.5 m).
Features:
LCD display
Auto. reference optimisation
Adjustment program CAL
Reference quantity selectable
Display switching piece/weight
Weight deviation in % / g
Data output RS 232
Battery-operated - optional possible
Package contents:
Delivered in transport packaging incl. power supply.
Appropriate accessories:
073464 Rectangular weights M1/M2/M3, cast iron
Appropriate batteries:
1 pieces 055050.0700 - 6LR61 / 9.0 V (NOT included in scope of delivery).
Note:
Stand for elevating the evaluator (height approx. 450 mm) on request
Order ID Scales capacity Resolution Digit height Platform size Weight
kg g mm mm kg
073430.0400 30 / 60 10 / 20 25 522 x 403 x 90 16
073430.0600 60 / 150 20 / 50 25 522 x 403 x 90 16
073430.0700 60 / 150 20 / 50 25 650 x 500 x 105 28
073430.0900 150 / 300 50 / 100 25 650 x 500 x 105 28
073430.1100 3 / 6 1 / 2 25 318 x 308 x 75 4
073430.1120 15 / 35 5 / 10 25 318 x 308 x 75 4
073430.1140 30 / 60 10 / 20 25 318 x 308 x 75 4
073430.1160 60 / 150 20 / 50 25 318 x 308 x 75 4
073430.1180 150 / 300 50 / 100 25 522 x 403 x 90 16
073455 Milligram weights M1
Flat polygonal sheets
Order ID Weight Tolerance Accuracy class
073455.0010 1 mg ±0.20 mg M1
073455.0020 2 mg ±0.20 mg M1
073455.0030 5 mg ±0.20 mg M1
073455.0040 10 mg ±0.25 mg M1
073455.0050 20 mg ±0.30 mg M1
073455.0060 50 mg ±0.40 mg M1
073455.0070 100 mg ±0.50 mg M1
073455.0080 200 mg ±0.60 mg M1
073455.0090 500 mg ±0.80 mg M1

Brütsch/Rüegger Tools Ltd. • Heinrich Stutz-Strasse 20 • P.O. Box • CH-8902 Urdorf • www.brw.ch 389
