043812 Accessories FUTURO

Code 100/ 200 / 250
Order ID Designation
043812.0100 Set of clamping jaws 15 mm:
1 pair of stepped jaws, hardened and ground
1 pair of plastic jaws
1 V-jaws, hardened and ground, with stop pin
043812.0200 Set of clamping jaws 25 mm:
1 pair of stepped jaws, hardened and ground
1 pair of plastic jaws
1 V-jaws, hardened and ground, with stop pin
043812.0250 Clamping jaws set 35 mm:
1 pair of stepped jaws, hardened and ground
1 pair of plastic jaws
1 V-jaws, hardened and ground, with stop pin
043812.0300 Plastic clamping jaws set 15 mm
consisting of 5 pairs.

043812.0400 Plastic clamping jaws set 25 mm
consisting of 5 pairs.

043812.0450 Plastic clamping jaws set 35 mm
consisting of 5 pairs.

043812.8060 Plastic case FUTURO 15 / 25 / 35
for mini-vices:
15 / 93 x 60
25 / 113 x 90
35 / 168 x 113
044110 ALUFIX starter kit B
Locking clamp
With hydraulic central clamping to fix the workpiece in any position.
Kit content:
Clamping tool (clamping width max. 50 mm)
Ball joint
Articulated arm (radius of action 280 mm)
Base plate (Ø 100x25 mm/M8 centric)
Order ID 044110.0100

Application
044120 ALUFIX starter kit D
Holddown spring
Practical aid on 3D measuring machines - Screw in the post, press down the holddown spring
and clamp the workpiece.
Kit content:
1 holddown spring (60 mm)
1 holddown post (M6 x 60 mm)
Reducing bush, one of each size M8, M10, M12
Order ID 044120.0100
