043210 Parallel base set FUTURO
(Milling blocks) - Made of hardened steel, for use as a base for work pieces in a wide variety of
machining processes. The high precision of the parallel bases guarantees parallel clamping of the
work piece.
Features:
Nominal dimension information on the front face of the product
Nominal dimension tolerance in height + width ±0.01 mm
hardened approx. 60 HRC
fine ground plane-parallel in pairs
Pair tolerance (tp) in height IT5
Remaining measurements in accordance with DIN ISO 2768 medium
Package contents:
Delivered in transport packaging included wooden box.
Replacement parallel base pairs 043212
Order ID L Pairs Weight Profile
mm kg mm
043210.0100 100 20 2.180 2x5 / 2x10 / 2x15 /
2x20 / 3x6 / 3x11 /
3x16 / 3x21 / 4x7 /
4x12 / 4x17 / 4x22
/ 5x8 / 5x13 / 5x18
/ 5x23 / 6x9 / 6x14
/ 6x19 / 6x24
043210.0200 125 24 14 8x11 / 8x16 / 8x21
/ 8x26 / 8x31 /
8x36 / 10x13 /
10x18 / 10x23 /
10x28 / 10x33 /
10x38 / 12x15 /
12x20 / 12x25 /
12x30 / 12x35 /
12x40 / 14x17 /
14x22 / 14x27 /
14x32 / 14x37 /
14x42
043210.0300 150 24 17 8x11 / 8x16 / 8x21
/ 8x26 / 8x31 /
8x36 / 10x13 /
10x18 / 10x23 /
10x28 / 10x33 /
10x38 / 12x15 /
12x20 / 12x25 /
12x30 / 12x35 /
12x40 / 14x17 /
14x22 / 14x27 /
14x32 / 14x37 /
14x42
