Plates and mounting tools Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
042560 Measuring/testing plate made of hard natural stone DIN 876/I
Made from hard black natural stone, lapped testing surface.
Package contents:
Delivered with factory certificate.
Cleaning agent 042602
Support frame 042661
Order ID Length Width Thickness Evenness Weight
mm mm mm µm kg
042560.0100 400 250 60 14 18
042560.0200 400 400 60 14 29
042560.0300 630 400 80 16 60
042560.0400 800 500 100 18 120
042560.0500 1000 630 150 20 285
042560.0600 1200 800 150 22 432
042560.0700 1500 1000 200 25 900
042560.0800 2000 1000 250 30 1500
042580 Measuring/testing plate made of hard natural stone DIN
876/00
Made from hard black natural stone, precision-lapped testing surface.
Note:
Plates in other dimensions and evenness tolerances, as well as special versions with T-grooves or
threaded sleeves, can be delivered on request.
Package contents:
Supplied with factory certificate.
Cleaning agent 042602
Support frame 042661
Order ID Length Width Thickness Evenness Weight
mm mm mm µm kg
042580.0100 400 250 60 2.8 18
042580.0200 400 400 60 2.8 29
042580.0300 630 400 80 3.2 60
042580.0400 800 500 100 3.6 120

042584 Surface plate FUTURO DIN 876/2
Dark hard stone with dense structure and even coloration. The top side is machined to DIN 876, the
outer sides are finely machined and the lower side is smoothly machined. The edges are bevelled
as protection against damage.
Features:
Finely machined surface
Homogenous stone structure
Stress-free and deflection-resistant
Low thermal conductivity
Package contents:
Delivered in transport packaging.
Cleaning agent 042602
Individual supports 052804.3200
Order ID Length Width Thickness Evenness Weight
mm mm mm µm kg
042584.1180 820 580 50 36 74
042590 Measuring/testing plates FUTURO DIN 876/00
Made from hard dark stone with dense structure and even colouring. The top is machined in ac-
cordance with DIN 876, the outer sides are finely machined and the underside is machined clean.
Features:
Precision processed surface
Homogeneous stone structure
Thick plate cross-section
Unstressed and deflection-resistant
Low thermal conductivity
Package contents:
Delivered in transport packaging with factory certificate.
Cleaning agent 042602
Support frame 042661
Order ID Length Width Thickness Evenness
mm mm mm µm
042590.5330 800 500 100 3.6
042590.5440 1000 630 150 4.0
042590.5550 1200 800 160 4.4

042600 Maintenance paste for granite
For immaculately maintaining hard stone products. Restores the original shine to the treated sur-
face and has a lubricating effect.
Order ID Contents
042600.0100 0.5 kg

Code 100
