042710 Measuring workstation with granite tabletop DIN 876/00
Testing plate of black natural hard stone; precision-lapped testing surface. Safety support
frame with fittings for attaching a LISTA drawer unit. Working height approx. 950 mm.
Note:
Optional configurations with LISTA drawer unit:
042710.0100 / 800 x 500 mm
Lista 441125.0100 / 441125.0300 / 441125.0500
042710.0200 / 1000 x 630 mm
Lista 441135.0100 / 441135.0400
042710.0300 / 1200 x 800 mm
Lista 441162.0100 / 441162.0200 / 541167.0100
Package contents, standard:
Delivered with 3 point support kit, 4 adjusting feet and factory test certificate, without LISTA unit. Standard
Package contents LISTA option:
Delivered with 3 point support kit, 4 adjusting feet, factory test certificat, LISTA drawer unit (of
choice) including fastening kit.
Cleaning agent 042602
Order ID Size * Evenness Colour Weight
mm µm kg
042710.0100 800 x 500 3.6 Blue - RAL 5012 ~160
042710.0200 1000 x 630 4.0 Blue - RAL 5012 ~250
042710.0300 1200 x 800 4.4 RAL 5012 blue ~500
Used with LISTA unit (RAL 5012)
043100 Parallel base set DIN 6346 FUTURO
(Milling blocks) In special steel, 58-62 HRC hardened, ground in pairs, pair tolerance to IT5 tole-
rance. Nominal dimensions to DIN ISO 2768/Part 1, medium.
Package contents:
Delivered in transport packaging including wooden base.
Order ID Pairs Length Profile
mm mm
043100.0100 9 63 8 x 2.5 / 10 x 3.2 / 12 x 4 / 16 x 5
100 20 x 6.3 / 12 x 4 / 16 x 5 / 20 x 6.3 / 25 x 8
043100.0200 7 100 12 x 4 / 16 x 5 / 20 x 6.3 / 25 x 8
160 25 x 8 / 32 x 10 / 40 x 12
043100.0300 5 100 25 x 8 / 32 x 10 / 40 x 12
160 50 x 16 / 63 x 20 043100.0300
043170 Parallel base set FUTURO
(Milling blocks) – Hardened steel, for use as supports for workpieces during a wide range of
machining processes. The height tolerance of the parallel pair allows parallel clamping of the work-
piece.
Features:
Hardened approx. 58-60HRC
Ground plane-parallel in pairs
Pair height tolerance 0.01 mm
Nominal dimensions to DIN ISO 2768/Part 1 medium
Nominal dimension printed on product face
Package contents:
Delivered in transport packaging including wooden base.
Replacement parallels 042172
Order ID Length Pairs Profile
mm mm
043170.0100 150 14 10x14, 10x16, 10x18, 10x20, 10x22, 10x24, 10x26, 10x28,
10x30, 10x32, 10x35, 10x40, 10x45, 10x50
043172 Parallel base pair FUTURO
(Milling blocks) – Hardened steel, for use as supports for workpieces during a wide range of
machining processes. The height tolerance of the parallel pair allows parallel clamping of the work-
piece.
Features:
Hardened approx. 58-60HRC
Ground plane-parallel in pairs
Pair height tolerance 0.01 mm
Nominal dimensions to DIN ISO 2768/Part 1 medium
Nominal dimension printed on product face
Package contents:
Delivered in transport packaging
Order ID Length Profile Order ID Length Profile
mm mm mm mm
043172.0100 150 10 x 14 043172.0800 150 10 x 28
043172.0200 150 10 x 16 043172.0900 150 10 x 30
043172.0300 150 10 x 18 043172.1000 150 10 x 32
043172.0400 150 10 x 20 043172.1100 150 10 x 35
043172.0500 150 10 x 22 043172.1200 150 10 x 40
043172.0600 150 10 x 24 043172.1300 150 10 x 45
043172.0700 150 10 x 26 043172.1400 150 10 x 50
