Scribing tools                       Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
      041010   Bevel square with dial protractor TESA
      Type EAC - Manufactured from stainless steel, hardened and ground, with adjustable straigh-
      tedge. Easy and reliable direct read-off due to double, 2-colour scale. The angle measured
      in shown in the window on the round dial in increments of 10° and also by the position of the
      indicator on the dial face.
      Package contents:
      Delivered in case.
      Appropriates accessories:
      Replacement straightedge and other accessories on request.
      Order ID     Straight edge length  Scaling      Resolution
                        mm
      041010.0100       200             4 x 90°         5‘
      041010.0200       300             4 x 90°         5‘
      041025   Protractor with fine adjustment
      Made of stainless steel, with sliding and interchangeable measuring bar.
      Features:
      With panoramic magnifier
      Sliding straightedge
      Non-glare reading
      Parallax-free vernier reading
      Package contents:
      Delivered in case.
      Appropriate accessories:
      041030 Accessories for bevel squares with protractor
      Order ID     Straight edge length  Scaling      Resolution
                        mm
      041025.0100       200             4 x 90°       5‘ ( / °)
                                                        1
                                                         12
                                                        1
      041025.0200       300             4 x 90°       5‘ ( / °)
                                                         12
      041030   Accessories for bevel squares with protractor
      Order ID  Designation
      041030.0100 Straightedge 150 mm
      041030.0200 Straightedge 200 mm
      041030.0300 Straightedge 300 mm
      041050   Protractor with fine adjustment FUTURO
      Made of stainless steel, with sliding and interchangeable measuring bar.
      Features:
      With panoramic magnifier
      Sliding straightedge
      Non-glare reading
      Parallax-free vernier reading
      Package contents:
      Delivered in case, with one straightedge in each size 150 mm, 200 mm and 300 mm incl. certifi-
      cate.
      Order ID     Straight edge length  Scaling      Resolution
                        mm
      041050.0100    150 / 200 / 300    4 x 90°       5‘ ( / °)
                                                        1
                                                         12
      041075   Bevel square with digital protractor SYLVAC
      Swiss Made - 3-year guarantee. In a stainless version with fine adjustment, suitable for general-
      purpose measuring tasks. With blocking screw, straightedge fixing and data output Opto.
      Package contents:
      Delivered in case.
      Appropriate accessories:
      009145 Accessories SYLVAC
      054740 Radio module IBR rf1
      Appropriate batteries:
      1 pieces 055050.1400 - CR2032 / 3.0 V (included in scope of delivery).
      Order ID  Straight edge length  Resolution  Accuracy  Protection class  Digit height
                     mm                                    mm
      041075.0100    200     0.01° / 0°01‘  4‘   IP51      8.5
