Scribing tools                       Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
                                040974   Bevel square with protractor FUTURO
                                Open, semicircular protractor with graduation 0...180°, reading accuracy to 1°. Matt anti-glare
                                chrome-plated scale , with locking screw.
                                 Order ID         Partial arc Ø            Side length
                                                     mm                      mm
                                 040974.0100         80                      120
                                 040974.0200         120                     150
                                 040974.0300         150                     200
                                 040974.0400         200                     300
                                 040974.0500         300                     500
                                040976   Protractor digital FUTURO
                                Degree scale and measuring pointer made of stainless steel. All measuring edges are finely ground.
                                The movable measuring pointer can be fixed in place using a knurled nut.
                                Features:
                                Reading 0.05°
                                Measurement range 180°
                                Accuracy ±0.3°
                                Package content:
                                Supplied in synthetic leather bag.
                                Appropriate batteries:
                                1 pieces 055050.1400 - CR2032 / 3.0 V (included in scope of delivery).
                                 Order ID         Partial arc Ø            Side length
                                                     mm                      mm
                                 040976.0200         120                     150
                                 040976.0300         150                     200
                                 040976.0400         200                     300
                                040980   Bevel square with protractor
                                Brushed chrome plated  with adjustable bar and locking screw. For measuring angles of
                                10°...170°.
                                 Order ID         Partial arc Ø            Side length
                                                     mm                      mm
                                 040980.0100         100                     150
                                 040980.0200         150                     300
                                 040980.0300         200                     400
                                 040980.0400         250                     500
                                 040980.0500         300                     600
                                040984   Bevel square with protractor FUTURO
                                Open protractor with graduation 10°...170°, reading accuracy to 1°. Length-adjustable arm, arm
                                end 45° bevelled. Anti-glare chrome-plated scale, with locking screw.
                                 Order ID         Partial arc Ø            Side length
                                                     mm                      mm
                                 040984.0100         100                     150
                                 040984.0200         150                     300
                                 040984.0300         200                     400
                                040989   FUTURO combination square set
                                With angle measurer and centring square -  For use as a protractor, straightedge, rule, depth
                                gauge, stop square, centring square and mitre square, and as a spirit level with bubble tube.
                                Fixed scale 300 mm of hardened stainless steel. Angle part, angle measurer and centring square
                                are made of light metal alloy.
                                Package contents:
                                Delivered in case.
                                 Order ID                              040989.0100
