040470 Metalworker‘s try square
Made of steel, cleanly processed. Surface zinc-plated, uprights and flat sides smoothed.
Metalworker‘s squares are not standardised according to DIN. They should therefore only
be used for very simple tasks.
Order ID Side lengths Order ID Side lengths
mm mm
040470.0100 100 x 70 040470.0600 400 x 230
040470.0200 150 x 100 040470.0700 500 x 280
040470.0300 200 x 130 040470.0800 600 x 330
040470.0400 250 x 160 040470.0900 750 x 375
040470.0500 300 x 180 040470.1000 1000 x 500
040495 Mitre try square 135°
DIN 875/II
Made of steel, uprights precision-ground, flat sides processed.
Order ID Side lengths Order ID Side lengths
mm mm
040495.0100 120 x 80 040495.0300 200 x 130
040495.0200 150 x 100

040505 Acute angle 45°
DIN 875/II
Made of steel, uprights precision-ground, flat sides processed.
Order ID Side lengths Order ID Side lengths
mm mm
040505.0100 120 x 80 040505.0300 200 x 130
040505.0200 150 x 100

040510 Stop acute angle 45°
DIN 875/II
Made of steel, uprights precision-ground, flat sides processed.
Order ID Side lengths Order ID Side lengths
mm mm
040510.0100 120 x 80 040510.0300 200 x 130
040510.0200 150 x 100

040520 Flange square
Made of steel, zinc-plated. Uprights and flat sides processed.
Order ID Side lengths Flange width
mm mm
040520.0100 300 x 300 110 x 50
040520.0200 400 x 400 120 x 60
040520.0300 500 x 500 130 x 75

040534 FUTURO centring angle, DIN 875/I
Precision steel version with mm graduation on the scale. Ground functional sides ground, machi-
ned flat sides.
Order ID Side lengths for shafts Ø
mm mm
040534.0100 100 x 70 90
040534.0200 150 x 130 190
040534.0300 200 x 150 220

040555 Flat square
DIN 875/II
Made of steel, with uprights and flat sides ground, inspection faces precision-ground. For use in
general shop applications.
Package contents:
Delivered with factory certificate.
Appropriate accessories:
040645 Wooden case
Order ID Side lengths Order ID Side lengths Order ID Side lengths
mm mm mm
040555.0100 75 x 50 040555.0500 250 x 165 040555.0900 600 x 300
040555.0200 100 x 70 040555.0600 300 x 175 040555.1000 750 x 375
040555.0300 150 x 100 040555.0700 400 x 200 040555.1100 1000 x 500
040555.0400 200 x 130 040555.0800 500 x 250
