Scribing tools                       Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
                                040280   Precision straight-edge
                                Accuracy complies with DIN 874/00, control tool in a highly precise version, made of hardened
                                steel, non-glare black-oxide finish, precisely ground and lapped with insulated handle.
                                Package contents:
                                Delivered in leatherette case.
                                 Order ID    Length  Order ID   Length  Order ID    Length
                                              mm                 mm                 mm
                                 040280.0100  50    040280.0400  125    040280.0700  300
                                 040280.0200  75    040280.0500  150    040280.0800  400
                                 040280.0300  100   040280.0600  200    040280.0900  500
                                040290   Precision knife-edge straight-edge
                                Accuracy complies with DIN 874/00, control tool in a stainless version, made of hardened
                                steel, non-glare satin-finish, precisely ground and lapped with insulated handle.
                stainless       Package contents:
                                Delivered in leatherette case.
                                 Order ID    Length  Order ID   Length  Order ID    Length
                                              mm                 mm                 mm
                                 040290.0100  75    040290.0400  150    040290.0700  400
                                 040290.0200  100   040290.0500  200    040290.0800  500
                                 040290.0300  125   040290.0600  300
                                040295   Wooden case
                                for precision knife-edge straight-edge.
                                 Order ID   for length  Order ID  for length  Order ID  for length
                                              mm                 mm                 mm
                                 040295.0100  75    040295.0500  200    040295.0800  500
                                 040295.0200  100   040295.0600  300
                                 040295.0400  150   040295.0700  400
                                040302   FUTURO knife-edge straightedge set, DIN 874/00
                                Highly suitable for measurements all the way to the corners of grooves and blind holes.
                                Set consisting of 6 knife-edge straightedges, hardened and ground on all sides, accuracy complies
                                with DIN 874/00.
                                Knife-edge straightedge lengths:
                                8 / 12 / 16 / 20 / 30 / 40 mm
                                Knife-edge straightedge thickness:
                                5 mm
                                Package contents:
                                Delivered in wooden case.
                                 Order ID                              040302.0100
                                040420   Try square
                                Aluminium handle 40 x 14 mm matt anodised with recessed grip, blade made of stainless steel with
                                scale etched on both sides, gradation in mm, blade width 40 mm, blade thickness 1 mm.
                                 Order ID        Measuring jaw length      Handle length
                                                      mm                       mm
                                 040420.0100          200                      125
                                 040420.0200          250                      149
                                 040420.0300          300                      168
                                040440   Angle rule Hultafors
                                Blade made of stainless steel, handle made of aluminium with milled measuring surfaces, with
                                locking screw.
                                 Order ID                      Side length
                                                                 mm
                                 040440.0100                     200


                                040445   Angle rule
                                Beechwood handle with brass fittings, for internal and external measuring. hardened steel blade.
                                 Order ID       Side length   Order ID       Side length
                                                  mm                            mm
                                 040445.0200      250         040445.0300       300

                                040460   Metalworker‘s flat square
                                Made of steel, cleanly processed. Surface zinc-plated, uprights and flat sides smoothed.
                                Metalworker‘s squares are not standardised according to DIN. They should therefore only
                                be used for very simple tasks.
                                 Order ID       Side lengths  Order ID       Side lengths
                                                  mm                            mm
                                 040460.0100     100 x 70     040460.0600     400 x 230
                                 040460.0200     150 x 100    040460.0700     500 x 280
                                 040460.0300     200 x 130    040460.0800     600 x 330
                                 040460.0400     250 x 160    040460.0900     750 x 375
                                 040460.0500     300 x 180    040460.1000    1000 x 500
