P. 192

Scribing tools                       Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
      040170   Straightedge, steel
      Accuracy to DIN 874/2, ground on all sides, inspection faces precision-ground. Suitable for gene-
      ral scribing and set-up work.
      Note:
      From 4000 mm I-shaped cross-section with 2 hand slits, painted midsection
      Order ID    Length    Profile  Order ID  Length    Profile
                   mm       mm                 mm         mm
      040170.0100  500      30 x 6  040170.0600  2500    70 x 15
      040170.0200  750      40 x 8  040170.0700  3000    80 x 15
      040170.0300  1000     40 x 8  040170.0800  4000   100 x 16
      040170.0400  1500    50 x 10  040170.0900  5000   120 x 18
      040170.0500  2000    60 x 12
      040175   Straightedge, stainless steel
      Accuracy according to DIN 874/2, made of stainless steel, ground on all sides, inspection faces
      precision-ground. Suitable for general scribing and set-up work.
      Note:
      From 4000 mm I-shaped cross-section with 2 hand slits, painted midsection
      Order ID    Length    Profile  Order ID  Length    Profile
                   mm        mm                 mm        mm
      040175.0100  500      30 x 6  040175.0400  1500    50 x 10
      040175.0200  750      40 x 8  040175.0500  2000    60 x 12
      040175.0300  1000     40 x 8
      040180   Straightedge, steel
      Accuracy to DIN 874/1, ground on all sides, inspection faces precision-ground. Suitable for ins-
      pection purposes and precise work.
      Note:
      From 2000 mm I-shaped cross-section with 2 hand slits, painted midsection
      Order ID    Length    Profile  Order ID  Length    Profile
                   mm        mm                 mm        mm
      040180.0100  500      40 x 8  040180.0400  1500    60 x 12
      040180.0200  750      50 x 10  040180.0500  2000   70 x 15
      040180.0300  1000     50 x 10  040180.0600  2500   80 x 15
      040185   Straightedge, stainless steel
      Accuracy according to DIN 874/1, made of stainless steel, ground on all sides, inspection faces
      precision-ground. Suitable for inspection purposes and precise work.
      Note:
      From 2000 mm I-shaped cross-section with 2 hand slits, painted midsection
      Order ID    Length    Profile  Order ID  Length    Profile
                   mm        mm                 mm        mm
      040185.0100  500      40 x 8  040185.0300  1000    50 x 10
      040185.0200  750      50 x 10  040185.0400  1500   60 x 12
      040190   Straightedge, steel
      Accuracy according to DIN 874/0, ground on all sides, inspection faces precision-ground. Suita-
      ble for precise inspections and work.
      Note:
      From 2000 mm I-shaped cross-section with 2 hand slits, painted midsection
      The straightedges are also available in stainless steel
      Order ID    Length    Profile  Order ID  Length    Profile
                   mm        mm                 mm        mm
      040190.0100  500      50 x 10  040190.0300  1000   60 x 12
      040190.0200  750      50 x 10  040190.0400  1500   70 x 14
      040200   Cleaning / care cloths
      Cleaning - care - protection High-quality metal care and cleaning cloth. Suitable for all metals
      and metallic surfaces. Leaves behind an odourless, thin protective film that prevents subsequent
      fouling. Ideal for the cleaning and care of gauges, caliper engages, rulers etc.
      Package contents:
      Delivered in dispenser box.
      Order ID                               040200.0100




      040230   Precision straightedge made of granite
      Accuracy according to DIN 874/00, version with 2 even, lapped measuring surfaces. Use as a
      measuring and control straightedge for the most precise fine checking work.
      Order ID  Length  Profile  Evenness Order ID  Length  Profile  Evenness
                 mm    mm     µm             mm     mm      µm
      040230.0100  500  80 x 50  4  040230.0400  1500  180 x 80  11
      040230.0200  750  100 x 50  6  040230.0500  2000  220 x 100  14
      040230.0300  1000  140 x 60  7.5




      Brütsch/Rüegger Tools Ltd. • Heinrich Stutz-Strasse 20 • P.O. Box • CH-8902 Urdorf • www.brw.ch  187
