      040760   Stainless tool-and-die-maker square
      DIN 875/00
      Made of stainless hardened steel, with angles knife edge. Uprights ground and flat sides accu-
      rately precision ground. Inspection faces lapped. Suitable for fixture and tool construction.
      Order ID       Side lengths  Order ID        Side lengths
                        mm                           mm
      040760.0100      25 x 20     040760.0200      40 x 28



                                                                            stainless

      040780   Tool-and-die-maker square
      Precision version with accuracy in compliance with DIN 875/0 and movable knife-edge straigh-
      tedge. All measurement surfaces ground and lapped. Suitable for checking work via the air-gap
      method.
      Package contents:
      Delivered in case.
      Order ID                   Straight edge length
                                      mm
      040780.0100                    60 x 4 x 4
      040790   Tool-and-die-maker square
      Angle can be set - Made of steel, with chrome-plated read section. Angle adjustment using mi-
      crometer screw up to 5°, with division 5‘, accuracy 3‘, straightedge parallelism 0.001 mm. Suitable
      for measurement and checking work in tool and mould construction.
      Package contents:
      Delivered in case.
      Order ID   Straight edge length  Adjustability  Division  Handle length
                      mm                                 mm
      040790.0100     100           5°         5‘        60



      040795   Knife-edge straight-edges
      For tool-and-die-maker square with 5° setting option.C100:
      Designs:                                                            040795.0100
      040795.0100: Standard straightedge
      040795.0200: Straightedge with tapered end
      Order ID               040795.0100          040795.0200             040795.0200

      040820   Control tool set
      5-piece set, consisting of:
      Knife-edge straightedge, 100 mm, DIN 874/00
      Knife-edge straightedge, stainless 75 x 50 mm, DIN 875/00
      Tool-and-die-maker bevelled square, stainless 40 x 28 mm
      Tool-and-die-maker bevelled square, stainless 25 x 20 mm
      Gauge block scribing tip 60 x 8 x 8 mm
      Package contents:
      Delivered in case.
      Order ID                               040820.0100
      062420   Bevel gauge FUTURO
      For quick and exact checks of bevel angles. Exchangeable straightedges for 30°, 45° and 60°
      bevels.
      Package contents:
      Delivered in plastic box including 30°, 45° and 60° straightedges.
      Order ID           Range                    Vernier
                          mm                       mm
      062420.0100        0...10                    0.1




      040960   Bevel square
      Made of galvanised steel, not divided into degrees.
      Order ID        Side length  Order ID        Side length
                        mm                           mm
      040960.0100       200        040960.0400       400
      040960.0200       250        040960.0500       500
      040960.0300       300
