P. 191
Scribing tools Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
039810 Inside compass
Ground and polished version.
Order ID Length Order ID Length
mm mm
039810.0100 150 039810.0300 250
039810.0200 200 039810.0400 300
039820 Inside spring bow compass
Blank model with square-edged legs, quick nut and continuous spindle.
Order ID Side length Circle Ø max. Circle Ø min.
mm mm mm
039820.0200 100 100 17
039820.0300 125 130 17
039820.0400 150 160 17
039820.0600 200 190 18
039820.0700 250 230 19
039830 Caliper compass
Ground and polished version.
Order ID Length Order ID Length
mm mm
039830.0100 150 039830.0300 250
039830.0200 200 039830.0400 300
039840 Rod compass HELIOS PREISSER
Rode made of steel tube Ø 20 mm, with replaceable steel tips and mm division.
Appropriate spare parts:
039845 Replacement tips
Order ID Range Vernier Order ID Range Vernier
mm mm mm mm
039840.0100 500 0.1 039840.0300 1500 0.1
039840.0200 1000 0.1 039840.0400 2000 0.1
039845 Replacement tips
For trammel.
Ø 6 mm
Order ID Range Ø
mm mm
039845.0100 500...2000 6
186 Brütsch/Rüegger Tools Ltd. • Heinrich Stutz-Strasse 20 • P.O. Box • CH-8902 Urdorf • www.brw.ch
