Height gauges                        Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
                                037780   Height measuring /scribing instrument FUTURO HMD
                                Digital height gauge and scribing instrument with fine adjustment. Sturdy foot with ground base
                                surface. Large, easy-to-read LCD display; carbide-tipped scriber.
                                Features:
                                ON/OFF function
                                Zero setting in any position
                                mm/inch conversion
                                Package contents:
                                Delivered in transport packaging incl. scriber and ISO certificate.
                                Appropriate batteries:
                                1 pieces 055050.0900 - SR44  (357/303) / 1.55 V (included in scope of delivery).
                                 Order ID     Range      Resolution   Accuracy     Weight
                                               mm          mm          µm           kg
                                 037780.0020   300         0.01        ±40          4.6
                                 037780.0040   600         0.01        ±50          6.4




                                037786   Accessories FUTURO
                                 Order ID  Designation
                                 037786.0020 Scribing cutter with carbide tip 12 x 12 x 82 mm
                                037850   Height measuring / scribing instrument FUTURO HMA
                                Version with fine adjustment.
                                Features:
                                Sturdy cast foot with ground base surface
                                Brushed-chrome plated measuring rod and vernier
                                Measuring rod hardened and ground
                                Scribing blade offset and carbide-tipped
                                Package contents:
                                Delivered in transport packaging incl. factory certificate.
                                 Order ID    Range       Vernier     Accuracy      Weight
                                              mm          mm           µm           kg
                                 037850.0020  300         0.02        ±0.04         3.2
                                 037850.0040  600         0.02        ±0.07         7.2








                                037856   Accessories FUTURO
                                 Order ID  Designation
                                 037856.0020 Scribing cutter with carbide tip  6 x 8 x 75 mm for HMA 300 mm
                                 037856.0040 Scribing cutter with carbide tip  10 x 12 x 103 mm for HMA 600 mm

                                037880   Height measuring /scribing instrument FUTURO FDZ
                                Dual meter and dial gauge -  for rapid and reliable reading. Height adjustment with hand wheel,
                                scribing needle carbide-coated, round dial with 0.01 mm graduation. Two mechanical digital dis-
                                plays with counters running in opposite directions for whole millimetres. Both counters can be
                                independently set to zero as required.
                                Package contents:
                                Delivered in transport packaging.
                                Appropriate spare parts:
                                037890.0200 Scribing cutter for BRW 037880 HDZ
                                 Order ID    Range      Resolution    Accuracy     Weight
                                              mm          mm            µm          kg
                                 037880.0100  300         0.01          40          4.3







                                037890   Accessories FUTURO
                                for height measuring and scribing instrument HDZ
                                 Order ID  Designation
                                 037890.0200 Scribing blade FUTURO for HDZ
