037310 Probe set for height measuring instruments NÜSSLER
The universal T-probe made of carbide with ruby balls enables reliable and precise measurement
in a vertical as well as a horizontal position of Grooves, cut-ins, shoulders, cross-holes, etc.
Package contents:
Delivered in plastic box including T-probe, clamping shaft and hexagon key.
Note:
* TESA
** TRIMOS, SYLVAC, MITUTOYO
Replacement probe 046890
Order ID Ball Ø Ball centre to centre Clamping shaft Ø
distance
mm mm mm
037310.0100 1 10 6*
037310.0200 2 20 6*
037310.0300 1 10 8**
037310.0400 2 20 8**
037600 Height measuring/scribing instrument MAHR Digimar
Digital version for scribing and marking workpieces and for measuring heights and distances. Er-
gonomic table plate with hardened and lapped base for smooth and easy movement. Rail and
slider of hardened stainless steel. Large handwheel for positioning and measuring. Additional fine
adjustment and locking screw.
Features:
LCD display
Exchangeable measuring and scribing cutter, carbide-coated
Data output MarConnect
Package contents:
Delivered in transport packaging incl. scribing cutter and operating instructions.
Appropriate accessories:
009275 Accessories MAHR
055050 Batteries
Appropriate batteries:
1 pieces 055050.1400 - CR2032 / 3.0 V (included in scope of delivery).
Order ID 037600.0100 037600.0200
Model 814SR 814SR
Range mm 350 600
Resolution mm 0.01 0.01
Accuracy µm 40 50
Digit height mm 12 12
Weight kg 7 8
037605 Accessories MAHR
Order ID Designation
037605.0100 Measuring and scribing tip, carbide-tipped, 11.5 x 7 x 65 mm

037650 Height and scribing gauge SYLVAC Hi_Gage ONE
Swiss Made - 3-year guarantee. Handy and robust scribing gauge with large digital display.
Features:
ZERO / PRESET
Measuring direction selectable
Data output Proximity, Power
Package contents:
Delivered in transport packaging.
Appropriate accessories:
009145 Accessories SYLVAC
021540 Accessories SYLVAC
Appropriate batteries:
1 pieces 055050.1400 - CR2032 / 3.0 V (included in scope of delivery).
Order ID 037650.0100 037650.0200
Range mm 400 600
Resolution mm 0.01 0.01
Accuracy µm 40 60
Weight kg 4.7 6.5
037651 Accessories SYLVAC
Order ID Designation
037651.0010 Ball shank Ø 8 mm Ø 8 / Ø 8 x 76

037651.0030 Clamping shank Ø 8 x 20
