Miscellaneous drills Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
158181 Concrete drills BOSCH

N
Stone

CYL-5, hammer-resistant high-performance drill bit according to ISO 5468 for all impact drills
Version
Hardened steel body with active centring tip (activeteq) for active cutting in concrete and dia-
mond-ground cutting edges.
The new Power Grip System enables 100% of the machine’s power to be transferred to the drill
bit.
Application
Drilling holes in granite, concrete, masonry, limestone, natural and artificial stone.
Well suited for dowel drilling.
Is part of:
158191 Set of concrete drills BOSCH
Order ID d1 l1 l2 Order ID d1 l1 l2 Order ID d1 l1 l2
mm mm mm mm mm mm mm mm mm
158181.0100 3 90 50 158181.1100 6 250 2500 158181.2100 10 250 200
158181.0200 3.5 90 50 158181.1200 6.5 100 50 158181.2200 12 150 90
158181.0300 4 90 50 158181.1300 6.5 150 100 158181.2300 12 250 190
158181.0400 4 140 100 158181.1400 7 100 50 158181.2400 14 150 90
158181.0500 5 100 50 158181.1500 7 150 100 158181.2500 14 250 190
158181.0600 5 150 100 158181.1600 8 100 50 158181.2600 16 200 140
158181.0700 5.5 100 50 158181.1700 8 150 100 158181.2700 18 200 140
158181.0800 5.5 150 100 158181.1800 8 250 200 158181.2800 20 200 140
158181.0900 6 100 50 158181.1900 9 100 50
158181.1000 6 150 100 158181.2000 10 150 100
158191 Set of concrete drills BOSCH

N
Stone

Set of concrete drills CYL-5
Consisting of:
158181 Concrete drill CYL-5 hard-metal tipped
Order ID Range Dimensions Order ID Range Dimensions
mm mm mm mm
158191.0100 5...8 5/6/8 158191.0300 4...10 4/5/5/6/6/8/10
158191.0200 4...8 4/5/6/6/8
158425 Formwork drill bit BOSCH
HSS

P N
≤ 600

HSS, cylindrical, extra long, short helix, drill bit with conical cut 118°, according to DIN 7490.
Application:
For pipe penetrations in wood, brick, drywall, insulating and light building boards.
Note: Drill in a rotary motion only, without impact
Order ID d1 l1 d2 Order ID d1 l1 d2 Order ID d1 l1 d2
mm mm mm mm mm mm mm mm mm
158425.0100 6 400 5 158425.1000 14 600 8 158425.1900 24 400 11
158425.0200 6 600 5 158425.1100 16 400 10 158425.2000 24 600 11
158425.0300 8 400 6 158425.1200 16 600 10 158425.2100 25 400 11
158425.0400 8 600 6 158425.1300 18 400 10 158425.2200 26 400 11
158425.0500 10 400 8 158425.1400 18 600 10 158425.2300 26 600 11
158425.0600 10 600 8 158425.1500 20 400 10 158425.2400 28 400 11
158425.0700 12 400 8 158425.1600 20 600 10 158425.2500 28 600 11
158425.0800 12 600 8 158425.1700 22 400 10 158425.2600 30 400 11
158425.0900 14 400 8 158425.1800 22 600 10 158425.2700 30 600 11
