Miscellaneous drills Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
158359 Wood drill bit set BOSCH

N
Wood

7-piece
With central spur and leading lips on the cutting edges.
Application: For hard and soft wood.
Order ID Range Dimensions
mm mm
158359.0100 3...10 3/4/5/6/7/8/10

158360 Wood twist drill

N
Wood

With central spur and leading lips on the cutting edges.
Application: For hard and soft wood.
Order ID d1 l2 d2 l1 Order ID d1 l2 d2 l1
mm mm mm mm mm mm mm mm
158360.0100 3 33 3 61 158360.0900 11 89 8 142
158360.0200 4 43 4 75 158360.1000 12 96 8 151
158360.0300 5 52 5 86 158360.1100 13 96 10 151
158360.0400 6 57 6 93 158360.1200 14 96 10 151
158360.0500 7 69 7 109 158360.1300 15 100 10 160
158360.0600 8 75 8 117 158360.1400 16 100 10 160
158360.0700 9 81 9 120 158360.1500 18 120 10 180
158360.0800 10 87 10 133 158360.1600 20 130 10 200
158410 Multi-spur bits in carbide

N
Wood

Similar to DIN 7483G, with centre point, two roughing, two cutting edges and offset cylindrical
shank.
Application
Precise drilling in uncoated hard and soft woods as well as uncoated particle boards. For use in
electric handheld drills and drilling machines.
Shank versions:
15 mm...30 mm: Shank 8 x 30 mm
35 mm...50 mm: Shank 10 x 30 mm
Is part of:
158420 Set of carbide multi-spur bits
Order ID d1 l1 Order ID d1 l1 Order ID d1 l1
mm mm mm mm mm mm
158410.0200 15 90 158410.0700 24 90 158410.1100 40 90
158410.0400 18 90 158410.0800 25 90 158410.1200 45 90
158410.0500 20 90 158410.0900 30 90 158410.1300 50 90
158410.0600 22 90 158410.1000 35 90
158420 Set of carbide multi-spur bits

N
Wood

5-piece, in wooden case.
Consisting of:
158410 C-multi-spur machine bit with centre point
Order ID Size Contents
158420.0100 1 15 / 20 / 25 / 30 / 35
