Miscellaneous drills Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
158070 Glass and tile drill

HM

N
Stone

Diamond-ground carbide cutting edge with pointed conical grind for precise spot-drilling. Brazed
carbide tip, cylindrical shank.
Application: Boring porcelain, glass and tiles. Caution: not suitable for hardened glass.
Note: The drill should preferably be used with low speeds (100-200 rpm) and with cooling (water,
turpentine or kerosene).
Order ID d1 l1 Order ID d1 l1 Order ID d1 l1
mm mm mm mm mm mm
158070.0100 3 65 158070.0400 6 65 158070.0800 12 80
158070.0200 4 65 158070.0600 8 70
158070.0300 5 65 158070.0700 10 80
158071 Tile drill BOSCH
CYL-9 Ceramic

N
Stone

With centre point for a precise start without slipping off.
Application:
For all soft to medium hard tiles, porcelain, ceramics and non-toughened glass.
1 pack contains: 5 pieces
Is part of:
158072 Tile drill set BOSCH CYL-9 Ceramic
Note: Use at low speeds and without impact. No cooling required.
Order ID d1 l1 Order ID d1 l1 Order ID d1 l1
mm mm mm mm mm mm
158071.0100 3 70 158071.0500 6 80 158071.0900 10 90
158071.0200 4 70 158071.0600 6.5 80 158071.1000 12 90
158071.0300 5 70 158071.0700 7 80 158071.1100 14 90
158071.0400 5.5 70 158071.0800 8 80 158071.1200 16 90
158072 Tile drill set BOSCH
CYL-9 Ceramic

N
Stone

5-piece
With centre point for a precise start without slipping off.
Application:
For all soft to medium hard tiles, porcelain, ceramics and non-toughened glass.
Consisting of:
158071 Tile drill BOSCH CYL-9 ceramic
Note: Use at low speeds and without impact. No cooling required.
Order ID Range Dimensions
mm mm
158072.0100 4...10 4/5/6/8/10
158072.0200 5.5...10 5.5/6/7/8/10
