Physical measuring instruments Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
068895 Luxmeter TESTO 540
The measuring instrument in pocket size for measuring light intensity.
Features:
Sensor adapted to sensitivity of eyes
Functions HOLD / MAX / MIN
Service life of batteries 200 hours
Dimensions 133 x 46 x 25 mm
Light intensity:
Measuring range:
0...99999 lux
1 lux (0...19999 lux)
10 lux ( 20000...99999 lux)
Accuracy ±3% (to reference)
Units lux, foot-candle
Package contents:
Deliverd with hand loop, belt carrying case, protective cap and calibration report.
Appropriate batteries:
2 pieces 055050.0400 - LR03 / 1.5 V (AAA) (included in scope of delivery).
Order ID Type
068895.0100 540
068900 Luxmeter TESTO 545
For measurements in work places, offices, schools etc. The logger function allows long-term ob-
servation.
Features:
Up to 99 measurement locations storable
Logger function (3000 measurements)
Average value function
MAX / MIN function
RS-232 interface
Package contents:
Delivered in transport packaging incl. sensor and calibration report.
Appropriate batteries:
1 pieces 055050.0700 - 6LR61 / 9.0 V (included in scope of delivery).
Order ID Type Range Resolution Basic accuracy
TESTO 545 lx lx
068900.0100 545 0...+100000 1/0...+32‘000 ±1 Digit
10/0...100‘000
068960 Noise level meter TESTO
Simple to operate, compact, handy measuring device.
Note:
Accuracy Class 2 to DIN/IEC 60651 standard
Frequency analysis according to dBA and dBC criteria
MAX / MIN memory
Selectable timeline (fast/slow)
Additional features Type 816:
BarGraph display
Integrated memory for up to 31 000 readings
AC output for connecting recorders and amplifiers
DC output with 10 mV / dB to connect recorders or data loggers
PC software and USB cable for data transfer
068960.0100 Package contents:
Deliverd with microphone and windbreak.
Appropriate batteries:
1 pieces 055050.0700 - 6LR61 / 9.0 V (included in scope of delivery).
Order ID Type Range Resolution Accuracy
dB(A) dB dB
068960.0100 815 +32...+130 0.1 ±1.0

068970 Sound level measuring instrument
Features:
Fast response time
DATA-HOLD function
MAX-HOLD function
Accuracy class 2 according to IEC 651
AC outlet for connecting recorders and boosters
DC outlet with 10 mV/dB for connecting recording metres or data loggers
Frequency range low (Lo) dB(A) 35...100
Frequency range high (Hi) dB(A) 65...130
Operating temperature 0°C...+40°C
Dimensions 245 x 64 x 31 mm
Package contents:
Delivered in pouch.
Appropriate batteries:
1 pieces 055050.0700 - 6LR61 / 9.0 V (included in scope of delivery).
Order ID Type Range Resolution Accuracy
dB(A) dB dB
068970.0100 FSM130+ +35...+100 0.1 1.5
