Physical measuring instruments Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
069210 Hand-held piece counter ZIVY
Model Z 888 - Increments by one digit each time the button is pressed. Reset button on the side,
4-digit total, digit height 3.5 mm.
Order ID Model
069210.0100 Handmodell
069210.0200 Tischmodell
069210.0300 Wandmodell

Code 100
069230 Stroke counter ZIVY
Model Z 1040 - Very small model with reset button, increments by one digit for each complete
stroke cycle (backward and forward movement), no downcount, max. speed 500 strokes/min.,
stroke angle 36° - 60°, 5-digit total, digit height 4 mm.
RR/LL:
Drive right, right-turning
Drive left, left-turning
RL/LR:
Drive left, right-turning
Drive right, left-turning
Order ID Drive
069230.0100 RR/LL
069230.0200 RL/LR
069240 Stroke counter ZIVY
Model Z 4040 - With reset lever, operating and reset levers can be attached on right or left; incre-
ments by one digit for each stroke; especially suitable for installation on punches and presses, max.
speed 500 strokes/min., stroke angle 30°...60°, with 6-digit total, digit height 4.5 mm.
RR/LL:
Drive on right, clockwise rotation
Drive on left, anti-clockwise rotation
RL/LR:
Drive on left, clockwise rotation
Drive on right, anti-clockwise rotation
Order ID Drive
069240.0100 RR/LL
069240.0200 RL/LR

069250 Stroke counter ZIVY
Model Z 6040 - With reset lever, operating and reset levers can be attached on right or left; in-
crements by one digit for each stroke; robust, high-performance counter; max. speed 500 strokes/
min., stroke angle 40°...60°, with 6-digit total, digit height 7 mm.
RR/LL:
Drive on right, clockwise rotation
Drive on left, anti-clockwise rotation
RL/LR:
Drive on left, clockwise rotation
Drive on right, anti-clockwise rotation
Order ID Drive
069250.0100 RR/LL
069250.0200 RL/LR
069280 Revolution counter ZIVY
Model Z 1030 - Suitable for mounting on small machines, reset button can be mounted on left or
right, adds or subtracts one digit for each revolution, stainless steel drive spindle. 5-digit total, digit
height 4 mm, max. speed 1500 r.p.m.
RR/LL:
Drive right, right-turning
Drive left, left-turning
RL/LR:
Drive left, right-turning
Drive right, left-turning
Order ID Drive
069280.0100 RR/LL
069280.0200 RL/LR
