Physical measuring instruments Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
068590 Thermometer / hygrometer TESTO 625
A precise temperature measurement forms the correct basis for determining relative hu-
midity and dew point.
Measuring device with integrated, removable humidity/temperature sensor, suitable for the work-
shop and for measuring ambient conditions in work areas and store rooms etc. Illuminated display,
Hold function and Min/Max memory. The hand-held wireless unit (option) allows remote measu-
rements.
Features:
Backlit display
Hold function
MAX / MIN-memory
By radio handle (option) wireless measuring is possible
Package contents:
Delivered in transport packaging with sensor and calibration report.
Appropriate batteries:
1 pieces 055050.0700 - 6LR61 / 9.0 V (included in scope of delivery).
Appropriate accessories:
068190 Sensor
068200 Accessories
Order ID 068590.0200
Type 625
Range °C -10...+60
Range rF 0%...100%
Resolution 0.1%rF / 0.1°C
Accuracy ±2.5%rF / ±0.5°C
Measurements %rF / °C
068620 Hygrometer
For fast, non-destructive detection of moisture in building materials, floors, walls and ceilings. Also
ideal for floor layers for checking whether the subfloor is ready for laying. With LCD display, 3-digit
value that indicates the moisture gradient (increasing value = higher moisture), the ball probe mea-
sures in 20...40 mm depending on apparent density.
Features:
Backlit display
Hold function
MAX / MIN memory
Dimnensions 80 x 45 x 45 mm
Appropriate batteries:
1 pieces 055050.0700 - 6LR61 / 9.0 V (included in scope of delivery).
Order ID Type Measuring depth Range Resolution
mm
068620.0100 FFM100 20...40 0...100 Digits 1 Digit
