1 64330 Tap FUTURO

HSS-E M ISO 2 C
(6H) 2-3
N
Cu, AI

Metric ISO thread
With spiral flutes 40°, HSS-E, tolerance ISO2 / 6H.
Application
For aluminium.
End section C
Hole type: For pocket holes.
Designs
M2 - M10: reinforced shank.
M12 - M24: reduced shank.
Order ID d P DIN L l d1 a Ø
mm mm mm mm mm mm
164330.0030 M2 0.4 371 45 8 2.8 2.1 1.6
164330.0060 M2.5 0.45 371 50 9 2.8 2.1 2.05
164330.0100 M3 0.5 371 56 6 3.5 2.7 2.5
164330.0200 M4 0.7 371 63 7.5 4.5 3.4 3.3
164330.0300 M5 0.8 371 70 8.5 6 4.9 4.2
164330.0400 M6 1 371 80 11 6 4.9 5
164330.0500 M8 1.25 371 90 14 8 6.2 6.8
164330.0600 M10 1.5 371 100 16 10 8 8.5
164330.0700 M12 1.75 376 110 18.5 9 7 10.2
164330.0800 M16 2 376 110 20 12 9 14
164330.0900 M20 2.5 376 140 25 16 12 17.5
164330.1000 M24 3 376 160 30 18 14.5 21
1 64365 Micro thread former FUTURO
HSS-E TiN M ISO 2 C
(6HX) 2-3

P M N S
≤ 850 ≤ 900 Cu, AI Ti-Ni
≤ 900
Metric ISO thread
without lubrication groove, TiN, HSS-E, ~DIN371, tolerance ISO2/6HX.
Application
For all materials suitable for shaping,
with a breaking elongation of at least 10%.
Chamfer form C
Hole type:
For through holes and blind holes.
Order ID d P L l d1 a Ø
mm mm mm mm mm mm
164365.0100 M1 0.25 40 4 2.5 2.1 0.9
164365.0200 M1.2 0.25 40 4.8 2.5 2.1 1.1
164365.0300 M1.4 0.3 40 5.6 2.5 2.1 1.28
164365.0400 M1.6 0.35 40 6.4 2.5 2.1 1.46
164365.0500 M1.7 0.35 40 6.8 2.5 2.1 1.55
164365.0600 M1.8 0.35 40 7.2 2.5 2.1 1.66
164365.0700 M2 0.4 45 8 2.8 2.1 1.85
164365.0800 M2.5 0.45 50 9 2.8 2.1 2.30
