079810 ISO Tolerance slide gauge
German - French - Made of plastic, 300 x 88 mm, with nominal dimensions for locations of dril-
lings and shafts from 1...180 mm.
Order ID Size
mm
079810.0100 Ø 1...180
079830 Fit selector
German - French - Made of plastic, 110 x 280 mm, with all essential data regarding fits.
Front side: 34 tolerance fields
DIN 7157 nominal size range 1...500 mm.
Back side: 35 fits
DIN 7157 nominal size range 1...500 mm.
Order ID Size
mm
079830.0100 Ø 1...500
079850 Pitch gauge
German - French - Made of aluminium, Ø 80 mm.
Ranges:
ISO M 1.6...M 52
Ww 1/8“...2“
G 1/8“...2“
Order ID 079850.0100

079890 Screw selector
German - Made of plastic, 131 x 250 mm, with the most important sizes of ISO standard thread
and ISO fine threads M3...M125, design sizes, strength properties, tractive force, tightening torque
for screws and nuts.
Order ID Size
mm
079890.0100 M3...M125
079910 Thread size key FILETOR
Multilingual - In sealed plastic case, 110 x 60 x 30 mm, well protected from dirt and dust. Suitable
for determining the thread sizes of all the most important standard threads. Provides all information
necessary for measuring threads, including drill hole diameters. Designed for use in the workshop,
planning processes, design departments etc.
Thread types:
Metric, metric fine, American standard, American fine, Engl. Whitworth, Engl. Whitworth fine,
Engl. pipe, Engl. small, steel armoured pipe.
Ranges:
ISO M1...M6
ISO MF 1 x 0.2...MF 100 x 6
UNC 1 - 64...4 - 4
UNF 0 - 80...1 1/2 - 12
UNEF 12 - 32...1 11/16 - 18
Ww 1/16“...6“
BSF 3/16“...4 1/4“
GAS 1/8“...6“ (G = R)
BA 0...14
PG 7...48
Order ID 079910.0100
079920 ISO tolerance key
Multilingual - In sealed plastic case, 110 x 60 x 30 mm, well protected from dirt and dust. Suitable
for determining tolerance values to ISO 286-1988 standard; for range IT1 - IT16, has a full list of
ISO tolerances up to nominal size 500 mm, with over 6400 pairs of tolerance values. Designed for
use in the workshop, planning processes, design departments etc.
Order ID 079920.0100

080100 Slide rule for cutting speed
German - French - Made on aluminium, 140 x 90 mm.
Order ID 080100.0100
