054746 IBR software ComGage
ComGage is a software application for measurement and statistical process control during pro-
duction.
The software is suitable for simple displaying of measured values up to complex measuring appli-
cations with control sequences, as well as for the testing of components with multiple parameters
in small and large volume production. At the same time, statistical functions of ComGage supply
information about the control of production processes.
Features:
Simple, easy-to-follow operation
Low cost and modular
for general purpose use
Recording of measurements by measuring and interface devices as well as via keyboard
Supports many different measurement inputs and measurement programs
Graphical interface for creating the display windows
Easy control of measurement sequences
Online SPC elements
Control of command outputs and reading of digital inputs
Recording of master data
Printout of test reports and measurements in tabular form
Converter for Microsoft Excel and QS Stat
Master workstations:
Master workstations are used as an individual solution or in conjunction with several workstations
(measuring workstations).
Workstations:
Workstations are set measuring workstations and are only used for measuring / controlling. The
definition, management and analysis takes place via a master workstation.
Note:
For this product we recommend a training!
For further technical information, please ask for advice.
Appropriate accessories:
054735 Interface IBR IMBus
054740 Radio module IBR rf1
054741 Measurement processor

Order ID Designation Order ID Designation
054746.0010 ComGage Master complete: 054746.0050 ComGage Workstation without control functions:
is used as a master workstation for defining, measuring, cont- is used as a workstation (measuring workstation) for measuring
rolling and analysing with SPC display.
• Creation of test plans However, a Set Comgage Master is a requirement for compiling
• Job administration inspection plans
• Measuring, recording, computing and displaying measure- • Measuring, recording, computing and displaying measure-
ments ments
• SPC (statistical calculations and analyses) • SPC (statistical calculations and analyses)
• Control functions (digital input and output) • Dongle for enabling the program
• Dongle for enabling the program System requirements
System requirements Operating system: WXP, W7/32, W7/64, W8/32, W8/64
Operating system: WXP, W7/32, W7/64, W8/32, W8/64
054746.0020 ComGage Master programming and analysis: 054746.0060 ComGage Workstation with SPC and control functions:
is used as a master workstation for defining and analysing, but is used as a workstation (measuring workstation) for measuring
without measuring and control capabilities. However, a Set with SPC display and control functions. However, a Set Comga-
Comgage Workstation is a requirement ge Master is a requirement for compiling inspection plans
• Creation of test plans • Measuring, recording, computing and displaying measure-
• Job administration ments
• SPC (statistical calculations and analyses) • SPC (statistical calculations and analyses)
• Dongle for enabling the program • Control functions (digital input and output)
System requirements • Dongle for enabling the program
Operating system: WXP, W7/32, W7/64, W8/32, W8/64 System requirements
Operating system: WXP, W7/32, W7/64, W8/32, W8/64
054746.0030 ComGage Master programming and analysis: 054746.0070 ComGage Compact
is used as a master workstation for defining, measuring and ComGage Compact is a low-cost variant as a single workstation
analysing, but without control capabilities with limited functionality.
• Creation of test plans • maximum 20 features
• Job administration • maximum 20 testing stages
• Measuring, recording, computing and displaying measure- • no job administration
ments • no control functions
• SPC (statistical calculations and analyses) • no user administration
• Dongle for enabling the program • Dongle for enabling the program
System requirements System requirements
Operating system: WXP, W7/32, W7/64, W8/32, W8/64 Operating system: WXP, W7/32, W7/64, W8/32, W8/64
054746.0040 ComGage Workstation without SPC and control func-
tions:
is used as a minimal workstation (measuring workstation) for
measuring.
However, a Set Comgage Master is a requirement for compiling
inspection plans
• Measuring, recording, computing and displaying measure-
ments
• Dongle for enabling the program
System requirements
Operating system: WXP, W7/32, W7/64, W8/32, W8/64
