054740 Radio module IBR rf1
IBRit - rf1 radio module series used for wireless data transfer from measuring instruments to a PC.
The miniaturised replace measuring instrument connection cables and interface equipment.
Features:
Connection from 1...512 measuring equipment
Linking of several computers
Easy handling
Compact design
Rational operation
Complete data security
Range 20...200 m
CE + FCC approval
Transmission acknowledgement
Tolerance feedback
Individually programmable
Note:
For this product we recommend a training!
For further technical information, please ask for advice.
Appropriate accessories:
054740 Radio module IBR rf1
054745.0100 Software IBR IBREXDLL
054746 IBR software ComGage
054741 Measurement processor
Order ID Type Designation
054740.0040 rf1-usb Radio module USB as base station for PC
054740.0050 rf1-com Radio module RS232 as base station for PC
Workstation 054740.0110 rf1-opto Radio module for measuring instruments with OPTO RS232 data
output (external antenna)
054740.0111 rf1-opto Radio module for measuring instruments with OPTO RS232 data
output (internal antenna)
054740.0140 rf1-S233 Radio module for SYLVAC measuring instruments with Power
RS232 (external antenna)
054740.0149 rf1-Proxi- Radio module for SYLVAC measuring instruments with Proximity
mity (external antenna)
054740.0150 rf1-prox wireless module for SYLVAC measuring instruments with Proxi-
mity (internal antenna)
054740.0210 rf1-mit1 Radio module for caliper gauges and dial gauges with Digimatic
data output (external antenna)
054740.0211 rf1-mit1 Radio module for caliper gauges and dial gauges with Digimatic
Workstation data output (internal antenna)
054740.0280 rf1-digi Radio module for measuring instruments with Digimatic data
output (external antenna)
054740.0281 rf1-digi Radio module for all measuring instruments with Digimatic data
output (internal antenna)
054740.0310 rf1-mahr Radio module for measuring instruments with MarConnect data
output (external antenna)
054740.0311 rf1-mahr Radio module for measuring instruments with MarConnect data
output (internal antenna)
054740.0610 rf1-232 Radio module open programming for measuring instruments
with RS232 data output
054740.0800 rf1-cab1 Radio module for soldering on original instrument cables (exter-
nal antenna)
