HSS Drilling Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
1 53470 Morse taper shank drill GÜHRING

HSS WN
α: 130º
P M K N
≤ 900

293, 298, 299, type GT100, HSS, works standard, extra-long.
Application
Particularly stable specialty drill, developed for drilling extremely deep holes. Suitable for drilling
cast iron and steels up to max. 1000 N/mm2.
Exception:
Cr-Ni steels, stainless steels and similar materials.
Order ID d l2 l1 MT Order ID d l2 l1 MT Order ID d l2 l1 MT
mm mm mm mm mm mm mm mm mm
153470.0100 14 500 600 1 153470.0800 16 650 750 2 153470.1700 22 500 600 2
153470.0200 14 650 750 1 153470.1100 18 500 600 2 153470.1800 23 500 600 2
153470.0300 14 850 1000 1 153470.1200 18 650 750 2 153470.1900 24 475 600 3
153470.0400 15 500 600 2 153470.1400 19 500 600 2 153470.2000 25 475 600 3
153470.0600 15 850 1000 2 153470.1500 20 500 600 2
153470.0700 16 500 600 2 153470.1600 21 500 600 2
1 53600 Set of twist drills TITEX
HSS DIN
α: 118º 338

P M K N
≤ 850 ≤ 900

In metal case, twist drills 152000, Type N, HSS, DIN 338.
Set 601 including tap drills: ø 3.3, 4.2, 6.8, 10.2 mm.
Order ID Assortment Range Increment Dimensions Contents Cassette
mm mm pieces
153600.0100 601 1...10.5 0.5 158 x 111 x 35 19 1100
153600.0200 604 1...6.0 0.1 158 x 111 x 43 50 1590
153600.0300 605 6...10 0.1 197 x 153 x 47 41 6100
1 53620 Set of twist drills TITEX
HSS-E DIN
α: 130º 338
P M N S
Cu Ti-Ni

In metal case, Twist drill, type VA
152140, DIN 338, HSS-E.
Application
Heat-resistant twist drill with specially designed geometry for use in hard-to-machine materials that
tend to be highly work-hardening, such as stainless steels, acid and heat-resistant steels, titanium.
Set including tap drills: Ø 3.3, 4.2, 6.8, 10.2 mm.
Order ID Type Range Increment Contents Dimensions Cassette
mm pieces mm
153620.0100 VA 1...10.5 0.5 24 194 x 111 x 54 1105
