Form/smooth/thread gauges Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
062060 Feeler gauges
Single piece - Length 100 mm, conical, in plastic bags of 5 (individual strips not supplied).
Order ID Thickness Length Tolerance Order ID Thickness Length Tolerance
mm mm mm mm mm mm
062060.0100 0.02 100 0.004 062060.2900 0.40 100 0.012
062060.0200 0.03 100 0.004 062060.3000 0.42 100 0.012
062060.0300 0.04 100 0.004 062060.3100 0.44 100 0.012
062060.0400 0.05 100 0.004 062060.3200 0.45 100 0.012
062060.0500 0.06 100 0.004 062060.3300 0.46 100 0.014
062060.0600 0.07 100 0.005 062060.3400 0.48 100 0.014
Set of 5. 062060.0700 0.08 100 0.005 062060.3500 0.50 100 0.014
062060.0800 0.09 100 0.005 062060.3600 0.55 100 0.014
062060.0900 0.10 100 0.005 062060.3700 0.60 100 0.014
062060.1000 0.11 100 0.005 062060.3800 0.65 100 0.014
062060.1100 0.12 100 0.005 062060.3900 0.70 100 0.017
062060.1200 0.13 100 0.005 062060.4000 0.75 100 0.017
062060.1300 0.14 100 0.006 062060.4100 0.80 100 0.019
062060.1400 0.15 100 0.006 062060.4200 0.85 100 0.019
062060.1500 0.16 100 0.007 062060.4300 0.90 100 0.022
062060.1600 0.17 100 0.007 062060.4400 0.95 100 0.022
062060.1700 0.18 100 0.007 062060.4500 1.00 100 0.024
062060.1800 0.20 100 0.008 062060.4600 1.10 100 0.024
062060.1900 0.22 100 0.008 062060.4700 1.20 100 0.024
062060.2000 0.24 100 0.008 062060.4800 1.30 100 0.028
062060.2100 0.25 100 0.009 062060.4900 1.40 100 0.028
062060.2200 0.28 100 0.009 062060.5000 1.50 100 0.028
062060.2300 0.30 100 0.009 062060.5100 1.60 100 0.033
062060.2400 0.32 100 0.011 062060.5200 1.70 100 0.033
062060.2500 0.34 100 0.011 062060.5300 1.80 100 0.033
062060.2600 0.35 100 0.011 062060.5400 1.90 100 0.035
062060.2700 0.36 100 0.012 062060.5500 2.00 100 0.035
062060.2800 0.38 100 0.012
062070 Feeler gauge
Single blade - length 50 mm, with plastic handle. Narrow design (12.7 mm), suitable for places
that are difficult to access.
Order ID Thickness Grip colour Length Tolerance
mm mm mm
062070.0100 0.05 light blue 50 ±0.004
062070.0200 0.08 dark green 50 ±0.004
062070.0300 0.10 purple 50 ±0.005
062070.0400 0.15 white 50 ±0.005
062070.0500 0.20 blue 50 ±0.007
062070.0600 0.25 grey 50 ±0.008
062070.0700 0.30 yellow 50 ±0.009
062070.0800 0.35 light green 50 ±0.009
062070.0900 0.40 red 50 ±0.011
062070.1000 0.45 black 50 ±0.011
062070.1100 0.50 beige 50 ±0.014
062070.1200 0.55 claret 50 ±0.014
062070.1300 0.60 brown 50 ±0.017
062070.1400 0.70 orange 50 ±0.017
062070.1500 0.80 olive 50 ±0.020
062070.1600 0.90 pink 50 ±0.020
062070.1700 1.00 light grey 50 ±0.020

062110 Feeler gauge
13 blades - length 100 mm, tapered, in nickel-plated sheath.
Order ID Range Range Thickness
mm in mm
062110.0100 0.05...1.00 0.002...0.040 0.05 / 0.1 / 0.15 / 0.2 / 0.25 / 0.3 / 0.4
0.5 / 0.6 / 0.7 / 0.8 / 0.9 / 1.0

062120 Brass feeler gauge
13 blades - length 100 mm, brass (antimagnetic), tapered, in nickel-plated sheath.
Order ID Range Thickness
mm mm
062120.0100 0.05...1.00 0.05 / 0.1 / 0.15 / 0.2 / 0.25 / 0.3 / 0.4
0.5 / 0.6 / 0.7 / 0.8 / 0.9 / 1.0
062130 Feeler gauge
14 blades - length 100 mm, tapered, in nickel-plated sheath.
Order ID Range Thickness
mm mm
062130.0100 0.03...0.50 0.03 / 0.04 / 0.05 / 0.06 / 0.07 / 0.08 / 0.09
0.1 / 0.15 / 0.2 / 0.25 / 0.3 / 0.4 / 0.5

294 Brütsch/Rüegger Tools Ltd. • Heinrich Stutz-Strasse 20 • P.O. Box • CH-8902 Urdorf • www.brw.ch
