Stands / concentricity / balancing Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
027431 Measuring table SABI
Stable measuring table with fixture for vertical fine adjustment.
Features:
Base [mm] 80 x 130
Height [mm] 220
Capacity [mm] 60
Note:
The measuring inserts for the built-in micrometer can be interchanged and are not included and
must be ordered separately. Different models are available upon request.

027431.0300
Order ID Measuring height Range Resolution Fine adjustment
mm mm mm
027431.0100 65 0...25 0.01 yes
027431.0200 65 0...25 0.01 yes
027431.0300 65 0...25 0.01 yes
027431.0400 65 0...25 0.01 yes
027431.0500 65 0...25 0.001 yes
027431.0600 65 0...25 0.001 yes
027431.0700 65 0...25 0.001 yes
027431.0800 65 0...25 0.001 yes
027435 Ceramic measuring table SYLVAC
Cast foot, ceramic table plate. The measuring surface is extremely hard, corrosion-resistant and
absolutely non-wearing. Version with steel pillar, chrome-plated. Horizontal alarm fixed.
Package contents:
Delivered in transport packaging, dial gauge not included.
Appropriate accessories:
Dial gauges starting from 021450
Order ID 027435.0100
Measuring height mm 115
Capacity mm 78
Table size mm 85 x 85 x 25
Evenness µm 3
Vertical arm mm Ø 25
Height mm 215
Dial gauge holder mm Ø 8
Weight kg 4.3

027440 Ceramic measuring table BENZING
Table surface made from high-grade ceramic, lapped. Pillar - steel, hardened and precision-ground.
Versions:
027440.0100 /.0300 /.0500: Fixed horizontal arm
027440.0200 /.0400 /.0600: Horizontal arm adjustable
Package contents:
Delivered in transport packaging, without dial gauge.
Appropriate accessories:
Dial gauges starting from 021450
027440.0100 027440.0400
Order ID 027440.0100 027440.0200 027440.0300 027440.0400 027440.0500 027440.0600
Measuring height mm 100 100 100 100 150 150
Capacity mm 49 49 49 100 135 135
Table size mm Ø 50 Ø 50 65 x 75 65 x 75 98 x 115 98 x 115
Evenness µm 2.0 2.0 2.0 2.0 2.0 2.0
Vertical arm mm Ø 22 Ø 22 Ø 22 Ø 22 Ø 28 Ø 28
Horizontal arm mm - Ø 18 - Ø 18 - Ø 20
Height mm 200 200 200 200 284 284
Dial gauge holder mm Ø 8 Ø 8 Ø 8 Ø 8 Ø 8 Ø 8
Weight kg 2.3 2.3 3.2 3.2 7.1 7.1

Brütsch/Rüegger Tools Ltd. • Heinrich Stutz-Strasse 20 • P.O. Box • CH-8902 Urdorf • www.brw.ch 139
