027050 Measuring stand MAHR MarTest 801 p
Swivelling holder, base with V-notch 140°.
Package contents:
Delivered in transport packaging, without dial test indicator.
Appropriate accessories:
Dial gauges from 021450
Dial test indicators from 024210
Order ID 027050.0100
Height mm 150
Vertical arm mm Ø 8 x 130
Base mm 65 x 40
Dial gauge holder mm Ø 4 / Ø 8
Example of use
027060 Measuring stand INTERAPID
Cast base with ground finish, frontal stop face, pillar and arm of hardened steel, holder for dovetail,
round clamping system or eye. Zero-play fine adjustment with flat spring.
Package contents:
Delivered in transport packaging, without dial test indicator.
Appropriate accessories:
Dial gauges starting from 021450
Dial test indicators starting from 024210
Accessories 027150
Order ID 027060.0100 027060.0200
Height mm 177 314
Vertical arm mm Ø 8 x 136 Ø 17.8 x 250
Horizontal arm mm Ø 8 x 70 Ø 17.8 x 200
Base mm 98 x 70 150 x 120
027060.0100 Dial gauge holder mm Ø 8 Ø 8
Weight kg 1.3 4.35
027070 Measuring stand INTERAPID
With cast base, seat and bearing surfaces ground, fine adjustment, holder with dovetail and round
clamping system.
Package contents:
Delivered in transport packaging, without dial test indicator.
Appropriate accessories:
Dial gauges starting from 021450
Dial test indicators starting from 024210
Order ID 027070.0100
Height mm 243
Vertical arm mm Ø 17.8 x 175
Horizontal arm mm Ø 17.8 x 170
Base mm 200 x 55 x 35
Dial gauge holder mm Ø 8
Weight kg 3.3
Type UD 12
027100 Measuring stand FUTURO
Model with fine adjustment and V-block on the underside. Seat and bearing surfaces ground.
Holder for Ø 8 mm or for dovetail.
Package contents:
Delivered in transport packaging, without dial gauge.
Appropriate accessories:
Dial gauges starting from 021450
Dial test indicators starting from 024210
Order ID 027100.0100
Height mm 300
Vertical arm mm Ø 16
Horizontal arm mm Ø 16 x 180
Base mm 250 x 60 x 35
Dial gauge holder mm Ø 8
Weight kg 3.8
027150 Accessories for stands
Further accessories on request
Order ID Designation

027150.0050 Universal joint Ø 4 mm / Ø 8 mm

027150.0100 Universal joint Ø 8 mm / Ø 8 mm
