026870 Magnetic measuring stand QUICK-CHECK
Magnet can be switched on and off, gooseneck-like, lockable articulated arm bends and rotates,
also for hard-to-access locations.
Package contents:
Delivered in transport packaging, without dial gauge.
Appropriate accessories:
Dial gauges from 021450
Dial test indicators from 024210
Order ID 026870.0500
Length of the arm mm 285
Base mm 70 x 46 x 65
Adhesive strength N 600
Dial gauge holder mm Ø 8
026875 Accessories QUICK-CHECK
Order ID Designation
026875.0400 Swan neck complete, length 285 mm, receptacle M10

026875.0500 Magnetic base 70 x 46 x 65 / M10 / 600 N

026885 Magnetic measuring stand INTERAPID
Small, practical measuring stand with permanent magnet. Horizontal arm with fine adjustment,
clamping piece with dovetail and round clamping system.
Package contents:
Delivered in transport packaging, without dial test indicator.
Appropriate accessories:
Dial gauges from 021450
Dial test indicators from 024210
Order ID 026885.0100 026885.0200
Height mm 152 153
Vertical arm mm Ø 8 x 110 Ø 10 x 105
Horizontal arm mm Ø 8 x 80 Ø 8 x 68
Base mm Ø 35 x 42 Ø 50 x 47
Adhesive strength N 220 350
Dial gauge holder mm Ø 8 Ø 8
Type UJ 15 UJ 15G

026910 Magnetic measuring stand FUTURO
Small measuring stand with permanent magnet. Horizontal arm with fine adjustment, clamping
piece with dovetail and Ø 8 mm dial gauge Holder.
Package contents:
Delivered in transport packaging, without dial test indicator.
Appropriate accessories:
Dial gauges starting from 021450
Dial test indicators starting from 024210
Order ID 026910.0100 026910.0200
Height mm 170 190
Vertical arm mm Ø 10 Ø 10
Horizontal arm mm Ø 8 x 130 Ø 8 x 130
Base mm Ø 35 x 30 Ø 40 x 50
Adhesive strength N 250 400
Dial gauge holder mm Ø 8 Ø 8
Weight kg 0.6 0.6
026950 Magnetic holder
Designs:
026950.0100: With height and lateral adjustment, low overall height
026950.0200: Prismatic base and both long sides magnetic, holder can be swivelled in every po-
sition
026950.0300: With round foot
Package contents: 026950.0100 026950.0200
Delivered in transport packaging, without dial gauge.
Appropriate accessories:
Dial gauges from 021450
Dial test indicators from 024210
Order ID 026950.0100 026950.0200 026950.0300
Height mm 46 59 65
Capacity mm 35 35 13
Base mm 73 x 38 72 x 37 Ø 40
Adhesive strength N 180 180 180
Dial gauge holder mm Ø 8 Ø 8 Ø 8
