Stands / concentricity / balancing Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
026835 Magnetic measuring stand MAGNET-FIX
Swiss Made
Premium Brand with switchable prismatic magnetic foot and fine adjustment.
Package contents:
Delivered in transport packaging, without dial gauge.
Appropriate spare parts:
026840 Accessories for MAGNET-FIX
Appropriate accessories:
Dial gauges starting from 021450
Dial test indicators starting from 024210
Order ID 026835.0100
Height mm 230
Vertical arm mm Ø 15x230
Horizontal arm mm Ø 12x140
Base mm 65x70x56
Adhesive strength N 1250
Dial gauge holder mm Ø 8
026840 Accessories for MAGNET-FIX
Order ID Designation
026840.0100 Universal joint Ø 12 / Ø 15 mm

026840.0200 Dial gauge holder Ø 8 mm

026840.0300 Magnetic base 65 x 70 x5 6 mm, adhesive strength 1250 N

026840.0400 Horizontal arm Ø 12 x 140 mm
026850 Magnetic measuring stand
For control measurements with dial gauges and fine probes. Precision stand, solid construction, on/
off prismatic magnet foot.
Package contents:
Delivered in transport packaging, without dial gauge.
Appropriate accessories:
Dial gauges from 021450
Dial test indicators from 024210
Order ID 026850.0100 026850.0200
Height mm 285 500
Vertical arm mm Ø 16x220 Ø 20x420
Horizontal arm mm Ø 16x180 Ø 16x180
Base mm 70x46x65 75x60x80
Adhesive strength N 600 800
Code 100 Dial gauge holder mm Ø 8 Ø 8
026860 Magnetic measuring stand FUTURO
Stable and versatile measuring stand with fine adjustment and on/off magnetic foot.
Package contents:
Delivered in transport packaging, without dial gauge.
Appropriate accessories:
Dial gauges starting from 021450
Dial test indicators starting from 024210
Order ID 026860.0200
Height mm 275
Vertical arm mm Ø 16
Horizontal arm mm Ø 12 x 200
Base mm 60 x 50 x 55
Adhesive strength N 580
Dial gauge holder mm Ø 8
