Page 610 - Benma | Blue book 5.0

Milling burs Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
130200 Carbide mini burr FUTURO
ZYA
P M K N S H
Cu Ti-Ni 44-56
HRC
Cylindrical shape without end cut.
Crosscut.
Order ID Type d1 l2 d2 l1
mm mm mm mm
130200.0100 FA 0106-3 1.5 6 3 38
130200.0200 FA 0211-3 2.5 11 3 38
130200.0300 FA 0314-3 3 14 3 38
130200.0400 FA 0413-3 4 12.7 3 38
130200.0500 FA 0613-3 6.3 12.7 3 50
130210 Carbide mini burr FUTURO
ZYAS
P M K N S H
Cu Ti-Ni 44-56
HRC
Cylindrical shape with end cut.
Crosscut.
Order ID Type d1 l2 d2 l1
mm mm mm mm
130210.0100 FB 0106-3 1.5 6 3 38
130210.0200 FB 0211-3 2.5 11 3 38
130210.0300 FB 0314-3 3 14 3 38
130210.0400 FB 0604-3 6.3 4.7 3 43
130220 Carbide mini burr FUTURO
WRC
P M K N S H
Cu Ti-Ni 44-56
HRC
Sphero-cylinder shape.
Crosscut.
Order ID Type d1 l2 d2 l1
mm mm mm mm
130220.0100 FC 0211-3 2.5 11 3 38
130220.0200 FC 0314-3 3 14 3 38
130220.0300 FC 0413-3 4 12.7 3 38
130220.0400 FC 0513-3 5 12.7 3 38
130220.0500 FC 0613-3 6.3 12.7 3 50
130230 Carbide mini burr FUTURO
KUD
P M K N S H
Cu Ti-Ni 44-56
HRC
Ball shape.
Crosscut.
Order ID Type d1 l2 d2 l1
mm mm mm mm
130230.0100 FD 0202-3 2.5 2.3 3 38
130230.0200 FD 0302-3 3 2.5 3 38
130230.0300 FD 0403-3 4 3.4 3 38
130230.0400 FD 0504-3 5 4.7 3 38
130230.0500 FD 0605-3 6.3 5.0 3 44

130240 Carbide mini burr FUTURO
TRE
P M K N S H
Cu Ti-Ni 44-56
HRC

Oval shape.
Crosscut.
Order ID Type d1 l2 d2 l1
mm mm mm mm
130240.0100 FE 0305-3 3 5.5 3 38
130240.0200 FE 0507-3 5 7.1 3 38
130240.0300 FE 0609-3 6.3 9.5 3 47
Brütsch/Rüegger Tools Ltd. • Heinrich Stutz-Strasse 20 • P.O. Box • CH-8902 Urdorf • www.brw.ch 601
