Dial gauges Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
024920 Measuring inserts GIROD M1.4
Measuring inserts with thread M1.4 for Girod dial test indicators. Version with carbide ball or ruby
ball.
Appropriate accessories:
12mm / 36 mm - carbide Accessories 025410
Order ID Ball Ø Probe Material
mm mm
024920.0100 1 12 Carbide
024920.0200 2 12 Carbide
024920.0300 3 12 Carbide
12mm / 36 mm - ruby 024920.0400 1 36 Carbide
024920.0500 2 36 Carbide
024920.0600 3 36 Carbide
024920.0700 1 12 Ruby
024920.0800 2 12 Ruby
024920.0900 3 12 Ruby
Touch probe key BRW 024920.1000 1 36 Ruby
(BRW ) 024920.1100 2 36 Ruby
024920.1200 3 36 Ruby
025210 Dial test indicator set FUTURO
standard
3-year guarantee - standard version for workshop and inspection room. Suitable for difference
measurements, measurements of shape, position and place deviations as well as radial and axial
runout.
Features:
Measures in 2 directions
Low measuring force
Measuring stylus M1.6 with carbide ball Ø 2 mm
Package contents:
1 Lever test indicator, complete
1 clamping shaft Ø 4 mm with dovetail
1 clamping shaft Ø 8 mm with dovetail
1 clamping shaft, rectangular, shank Ø 6.30 mm
1 universal joint Ø 6.30 / Ø 8 mm
1 touch probe key
1 Plastic holster
1 ISO certificate
025210.0400 025210.0300
Appropriate accessories:
Measuring inserts 025211
Accessories 025410
Order ID Travel Resolution Bezel Ø Accuracy Repeatability Lettering Probe
mm mm mm µm mm
025210.0100 0.8 0.01 28 DIN 2270 3 0...40...0 11.9
025210.0200 0.8 0.01 38 DIN 2270 3 0...40...0 11.9
025210.0300 0.8 0.01 28 13 µm 5 0...40...0 33.6
025210.0400 0.8 0.01 38 13 µm 5 0...40...0 33.6
025210.1500 0.2 0.002 28 4 µm 3 0...10...0 12.9
025210.1520 0.2 0.002 38 4 µm 3 0...10...0 12.9
025211 Measuring inserts FUTURO M1.6
Measuring styli with thread M1.6 for FUTURO dial test indicators.
Features:
Version in stainless steel with carbide ball
Order ID Ball Ø Probe Material
mm mm
025211.0100 2 11.9 Carbide
025211.0200 1 11.9 Carbide
025211.0300 2 12.9 Carbide
025211.0400 1 12.9 Carbide
025211.0500 2 33.6 Carbide
