Caliper gauges Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
009234 Caliper gauge dig. MITUTOYO
Series 573 - ABSOLUTE Digimatic. With slidable measuring jaws for measuring bore centre dis-
tance. For borehole diameters of 1.5 mm to 10 mm.
Versions:
Type L: data output
Features:
LCD display
ABSOLUTE™ system
ORIGIN (ABS zero point)
OFFSET
PRESET
Automatic shutdown
Data output Digimatic
Package contents:
Delivered in case.
Appropriate accessories:
009245 Accessories MITUTOYO
054558 Interface MITUTOYO USB Input Tool Direct
054585 Interface MITUTOYO U-WAVE
Appropriate batteries:
1 pieces 055050.0900 - SR44 (357/303) / 1.55 V (included in scope of delivery).
Order ID Type Range Resolution Measuring jaw length Protection class Digit height
mm mm mm mm
009234.0100 L 10...160 0.01 30 IP67 7.5
009234.0200 L 10...210 0.01 30 IP67 7.5
009234.0300 L 10...310 0.01 30 IP67 10.2
009235 Digital caliper gauge MITUTOYO
Series 573 - ABSOLUTE Digimatic. ABS. Caliper gauge with fine outside measuring jaws.
Versions:
Type C: depth gauge rectangular, data output
Features:
LCD display
ABSOLUTE™ system
ORIGIN (ABS zero point)
Automatic shutdown
Data output Digimatic
Package contents:
Delivered in case.
Appropriate accessories:
009245 Accessories MITUTOYO
054558 Interface MITUTOYO USB Input Tool Direct
054585 Interface MITUTOYO U-WAVE
Appropriate batteries:
1 pieces 055050.0900 - SR44 (357/303) / 1.55 V (included in scope of delivery).
Order ID Type Range Resolution Measuring jaw length Protection class Digit height
mm mm mm mm
009235.0100 C 150 0.01 40 IP67 7.5
009245 Accessories MITUTOYO
Order ID Designation
009245.0100 Signal line DIGIMATIC 1 m,
with data button
009245.0200 Signal line DIGIMATIC 2 m,
with data button
009245.0300 (IP66 / IP67) Signal line 1 m
009245.0400 (IP66 / IP67) Signal line 2 m
009245.0500 Hold unit
009245.0600 Measuring bridge, base 75 x 12 for caliper gauges 150/200 mm
009245.0700 Measuring bridge, base 100 x 12 for caliper gauge 150/200 mm
009245.0800 Measuring bridge, base 125 x 14 for caliper gauge 300 mm
